FATEK FBs-CB2 - Page 102

3-6
FUN
No.
Name Operand
Derivative
instruction
Function descriptions
56
G→B
S,D DP Gray code to Binary conversion
57 DECOD S,Ns,NL,D P
Decode the binary data formed by N
L bits starting from Ns bit within
S, and store the result in the register starting from D
58 ENCOD S,Ns,NL,D P
Encoding the N
L bits starting from the Ns bit within S, and store the
result in D
59
→7SG
S,N,D P
Convert the N+1 number of nibble data within S, into 7 segment
code, then store in D
60
→ASC
S,D P
Write the constant string S (max. 12 alpha-numeric or symbols) into
the registers starting from D
61
→SEC
S,D P
Convert the time data (hours, minutes, seconds) of the three
successive registers starting from S into seconds data then store to
D
62
→HMS
S,D P
Convert the seconds data of S into time data (hours, minutes,
seconds) and store the data in the three successive registers starting
from D
63
→HEX
S,N,D P
Convert the successive N ASCII data starting from S into
hexadecimal data and store them to D
64
→ASCⅡ
S,N,D P
Convert the successive N hexadecimal data starting from S into
ASCII codes and store them to D
 Flow Control Instructions
 0
MC N The start of master control loop
 1
MCE N The end of master control loop
 2
SKP N The start of skip loop
 3
SKPE N The end of skip loop
END End of Program
65 LBL
1～6
alphanumeric
Define the label with 1~6 alphanumeric characters
66 JMP LBL P Jump to LBL label and continues the program execution
67 CALL LBL P Call the sub-program begin with LBL label
68 RTS Return to the calling main program from sub-program
69 RTI Return to interrupted main program from sub-program
70 FOR N Define the starting point of the FOR Loop and the loop count N
71 NEXT Define the end of FOR loop
