Appendix -1
Appendix FB-DAP Simple Human Machine Interface
In addition to timer, counter, register, and contact data access function, the date setter of FB-DAP can connect to
many others for alarm message display, self-defined buttons, wireless card reading, and the like simple human-machine
(HM) functions.
FB-DAP Simple HM
Model
Spec.
FB-DAP-A(R) FB-DAP-B(R)
Display LCD (English version), 2-line×16-character, LED backlight
Button 20-key (4×5)
Wireless Card reading
−AR and−BR only，distance 12～18cm
Power supply 5V 24V
Current consumption 100mA (120mA) 41mA (48mA)
Com. Interface HCMOS RS-485
Service points
connected
Single set Max. 16-set connected
PLC Com. Port
connected
port 0
port 0,1,2 (In which port 0 and 1
needed to be converted as RS-485)
General feature
Timing/counting、register、contact access(write protected for each)
Special feature
Alarm、message display、self-definition of special speed keys
Card writing feature Order for machine types with special numbers to us is required
※ PLC’s MA、MU type machines can be connected to FB-DAP-B(R) only through FB-485 switch.
Wireless sensing card
Model
Spec.
CARD-1 CARD-2
Memory 64bits with Cyclic Redundancy Check (CRC) on data
Operation temp.
−25°C～50°C (conforming to ISO7810)
Power supply
Battery not required (power supplied from wireless electric waves released by an
−AR/−BR card-reading module)
Sensing distance
12cm～18cm(from FB-DAP front)
Number of writing
unwritable(uncopiable，exclusively)
10000 times at least
Size (mm) 86×54×13
Weight (Gram) 12
