Appendix -8
【Example】Assume definition as R0, defined as M0 mode 1 (Reset).
After entering 16 soft key mode in function 9,
Press
Ö Display the address or DOC of R0, and then pressing , its corresponding
M1850 will be ON; OFF after it is released.
Ö Display the address or DOC of M0 and force M0 OFF.
Note 1：After the 16 soft keys are defined, once function 9 is executed, it will enter 16 soft key operation mode
and then the 16 soft keys will be executed according to function 8 definition.
Note 2：to return to normal operation mode, press〝
+ ( +++) +
〞。
z FUN 11（SET DAP NO.）：When several sets are connected, set DAP number.
After any communication of FB-PLC is converted to RS-485 interface (Among which port2 as such is a
RS-485 interface), the FB-DAP-B(R) of the 16 sets can be connected. Each DAP shall need a unique number,
1~16 (but one of them must be number 1). This DAP is not related to PLC numbers, meaning the number can have
the same PLC number.
z FUN 12（MAX. DAP NO. ON NETWORK）：when several sets are connected, set the biggest DAP number on the Web.
（Max. 16 DAPs, preset 7）
In a connection of several sets, FB-PLC can be joined with new DAPs. But the more the DAP number, the
longer the time to update information of each DAP. As a result, set the DAP number (the DAP number can not be
bigger than this number) on the Web appropriately will decrease time for information to update.
z FUN 13（WRITE PROTECT）：Information write in
Aimed for monitored items (T, C, R, D, Y, M, S), set the information in write-in protection separately. Just fill
in the corresponding place with 1, and then the item is write-in protected and can be read values only.
z FUN 14（RF CARD MODE）：Wireless card reading options
z MODE=〝0〞
Ö When reading a RF card, it will display whether this card is OK or Error. When the RF card is out of
sensing distance, it will pop up 〝NEXT〞, indicating another RF card is available now.
MODE=〝1〞
Ö once a RF card is read, it will beep once and will not display any information so the
sensing speed can be faster. But when many DAPs are connected, this mode will increase
by about 60mS to each set for monitored item information.
z FUN 15（RF CARD START ADDR.）：Start addresses storing the wireless RF card numbers
Store a card number’s address can be set through the function, ranging from D0~D2860 (preset to D2860).
Please refer to the Wireless Card Reading Functions in 1.6 for detailed description.
z FUN 16（ENABLE KEYS MAPPING）：Corresponding special contact of Enable key
After this function is set to 〝Enable〞 and enter SOFTKEY MODE（8KEYS and 16KEYS）, pressing a
definable soft key will force ON some contact of a corresponding contact under its number and the other contacts
become OFF. When set to “Disable”, the corresponding special contact of this DAP will not be effected.
