Appendix -13
3 Basic command signs
z
nS Left move speed (repeatable)
Message displayed at a left LCD move per n（1～255）× 0.1s。
z
nP Stop move (repeatable)
Message stop in（1～255）× 0.1s，and then move left at a configured speed.
z ，
Comma
Used as a statement to divide the file information. Information between two neighboring commas is a
complete and executable statement (unnecessary for the start and end of a file).
z
END End of a file
※ nS and nP commands will not be activated until after the information following them moves to the left
first place on the LCD display. They can have a repeatable arrangement of any place in ASCII, but the
same command cannot be connected together.
〈Example〉 Information edited with WinProladder ASCII file editor. R0 is a start register of an ASCII file
and the file information is shown as follows：
5S，20P，’A=’，〝6.2R3840〞，’B=’，〝6.2R3841〞，30P，’C： ’，〝1M0B〞，
’ D： ’，〝1M1B〞，’ E： ’，〝1M2B〞， ’ ’，END
If M1800 from 0→1 and R3780=0（i.e. R0）, Line 1 of the LCD of DAPs of all numbers is shown as follows：
Move a place left after stopping 2 seconds
Move a place left per 0.5s
After stopping 3s and then move a place left
Return to display again after reaching the end of the ASCII
※ Variable information is renewable anytime.
※ To display another message, just change R3780 value and not for M1800.
Always displayed in a cycle
︵
when
M1800
And
R3780
Are
Not
changed
︶
