H7-2
Differential
Output
Single-End Transistor Output Item
Specification
Ultra High
Speed
High
Speed
Medium
Speed
Low
Speed
Single-End Relay
Output
Single-End TRIAC
Output
Maximum switching
(working) Frequency
920KHz(1-phase)
460KHz(2-phase)
100KHz 20KHz 200HZ For ON/OFF, not for frequent exchange
Working Voltage
5VDC±10% 5～30VDC
<250VAC,30VDC 100～240VAC
Resistive
2A/single,
4A/common
1A
Maximum
Load
Current
Inductive
50mA 0.5A 0.1A 0.5A
80VA
15VA/100VAC
30VA/200VAC
Maximum Voltage Drop (@
maximum load)
－ 0.6V 2.2V 1.2V 0.06V(initial)
1.2Vrms
Minimum Load
－ －
2mA/DC power 25mA
Leakage Current
－ ＜0.1 mA/30VDC
－ 2mA
ON→OFF
15μS
1mS Maximum
Output
Delay
Time
OFF→ON
200nS 200nS
30μS
1mS 10mS
1/2AC period
Output Status Indication LED is bit when〝ON〞, dark when〝OFF〞
Over Current Protection N/A
Isolation Type Photo Coupler Isolation
Electromagnetic
Isolation
Photo Coupler Isolation
SINK/SRCE Output Type
Independent
Dual Terminals
for arbitrary
connection
Choose SINK/SRCE by models
and non-exchangeable
Bilateral device, can be arbitrarily set to
SINK/SRCE output
FBS-20MN(T,S)
Y0~1 Y2~7 Y2~7 Y2~7
FBS-32MN(T,S)
Y0~3 Y4~7 Y8~11
Y4~11 Y4~11
FBS-44MN(T,S)
Y0~7 Y8~15
Y8~15 Y8~15
FBS-10MC(T,S)
Y0,2 Y1,3
FBS-14MC(T,S)
Y0,2
Y1,3~5
FBS-20MC(T,S)
Y0,2
Y1,3~7
FBS-24MC(T,S)
Y0,2
Y1,3~7 Y8~9
FBS-32MC(T,S)
Y0,2
Y1,3~7 Y8~11
FBS-40MC(T,S)
Y0,2
Y1,3~7 Y8~15
FBS-60MC(T,S)
Y0,2
Y1,3~7 Y8~23
FBS-10MA(T,S)
Y0~3
FBS-14MA(T,S)
Y0~3 Y4~5
FBS-20MA(T,S)
Y0~3 Y4~7
FBS-24MA(T,S)
Y0~3 Y4~9
FBS-32MA(T,S)
Y0~3 Y4~11
FBS-40MA(T,S)
Y0~3 Y4~15
FBS-60MA(T,S)
Y0~3 Y4~23
List of Input Response Speed for Various Models
Expansion
Units/Modules(T,S)
All output
points
All output points All output points
*：The standard product of MC-type High-Speed output is 2 points, it can extend to 3~8points (Option). Every increment one High-speed
output point, and decrement one Middle-speed output point relatively. Only X4~X5,X8~X9 and X12~X13 output can be extended,
and the priority is low serial-number to High serial-number.
