Advanced Function Instruction
7-105
FUN122 P
MXOR
MATRIX EXCLUSIVE OR（XOR）
FUN122 P
MXOR
Ma :
EN Operation control
Ladder symbol
122P.MXOR
Mb :
L :
Md :
Ma : Starting register of source matrix a
Mb : Starting register of source matrix b
Md : Starting register of destination matrix
L : Length of matrix (Ma, Mb and Md)
Ma, Mb, Md may combine with V, Z, P0~P9 to serve
indirect address application
WX WY WM WS TMR CTR HR IR OR SR ROR DR K XR
Range
Ope-
rand
WX0
∣
WX240
WY0
∣
WY240
WM0
∣
WM1896
WS0
∣
WS984
T0
∣
T255
C0
∣
C255
R0
∣
R3839
R3840
∣
R3903
R3904
∣
R3967
R3968
∣
R4167
R5000
∣
R8071
D0
∣
D4095
2
∣
256
V、Z
P0~P9
Ma ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Mb ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
Md ○ ○ ○ ○ ○ ○ ○ ○* ○* ○ ○
L ○ ○* ○ ○
z When operation control "EN" = 1 or "EN↑" ( P instruction) has a
transition from 0 to 1, this instruction will performs a logic XOR (if
the 2 bits are different, then the result will be 1, otherwise it will be
0)between 2 source matrixes with a length of L, Ma and Mb. The
result will then be stored back into the destination matrix Md, which
also has a length of L. For example the XOR operation is done by
bits with the same bit numbers - for example, if Ma
0
= 0, Mb
0
= 1,
then Md
0
= 1; if Ma
1
= 1, Mb
1
= 1, then Md
1
= 0; etc, right up until
XOR reaches Ma
16L-1
and Mb
16L-1
.
L
Ma Mb Md
XOR
X0
EN
Ma :
Mb :
R 20
L : 5
R 10
R 0
Md :
122P.MXOR
z In the program at left, when X0 goes from 0→1, will
perform a XOR operation between matrix Ma, comprised
by R0 to R4, and matrix Mb, comprised by R10 to R14.
The results will then be stored in destination matrix Md,
comprised by R20 to R24. The results are shown at right
in the diagram below.
Ma15
↓
Ma
Ma0
↓
Mb
15
↓
Mb
Mb0
↓
Md15
↓
Md
Md0
↓
R0 0 0 0 0 0 0 0 0 0 0 0 0 00 0 0 R10 1111111111111111 R20 111 1 1 1 1 1 1 1 1 11111
R1 1 1 1 1 1 1 1 1 0 0 0 0 00 0 0 R11 0000000011111111 R21 111 1 1 1 1 1 1 1 1 11111
R2 0 0 0 0 0 0 0 0 1 1 1 1 11 1 1 R12 0000000011111111 R22 000 0 0 0 0 0 0 0 0 00000
R3 0 0 0 0 0 0 0 0 0 0 0 0 00 0 0 R13 0000000000000000 R23 000 0 0 0 0 0 0 0 0 00000
R4 1 1 1 1 1 1 1 1 1 1 1 1 11 1 1 R14 1111111111111111 R24 000 0 0 0 0 0 0 0 0 00000
↑
Ma79
↑
Ma64
↑
Mb79
↑
Mb64
↑
Md79
↑
Md64
Before execution After execution
