Appendix -7
z FUN 6（DEFINE SOFTKEY－8 KEYS）：Self-defining 8 soft keys
FUN 7（ENTER SOFTKEY MODE－8 KEYS）：Enter 8 soft key mode
1. Can self-define 8 soft keys：
、、、 、、 、 、
2. Definable range：R0～R3839、D0～D2943、M0～M1899.
3. In defining M0～M1899, this key can be defined as one of the 5 modes.
Mode Definition Description
0 Set
（S）
Set this contact to 1
1 Reset
（R）
Set this contact to 0
2 Moment
（M）
1 in pressing, 0 in being released
3 Inverse
（I）
Pressing once will have one inverse phase.
4 Monitor
（V）
Monitor this contact
【Example】 Assume definition as R0, definition as M0 mode 0(Set). Once enter the 8 soft key
mode in function 7,
Then pressing
Ö display address or DOC of R0.
Ö display
address or DOC of M0 and force M0 ON
Note 1：After defining the 8 soft keys, once function 7 is executed, it will enter 8 soft key operation mode.
And then the 8 soft keys will be executed according to function 6 definitions.
Note 2：
、
both are allowed out of definition, but the other keys will not be effected without
definition.
Note 3：To return to normal operation mode, press〝 +（D2972 content）+ 〞, among which
D2972 content is from 0000～9999（4 digits required）.
z FUN 8（DEFINE SOFTKEY－16 KEYS）：Self-define 16 soft keys
FUN 9（ENTER SOFTKEY MODE－16 KEYS）：Enter 16 soft key mode
1. Available for defining 16 soft keys：
、、、 、、 、 ～
2. Definable range：T0～T255、C0～C199、R0～R3839、D0～D2943、M0～M1899。
3. In defining M0～M1899, this key can be defined as one of the 5 modes and when a message is being
displayed, if the key is pressed, the display will not be changed.
Mode Definition Description
0 Set
（S）
Set this contact to 1
1 Reset
（R）
Set this contact to 0
2 Moment
（M）
1 in pressing, 0 in being released
3 Inverse
（I）
Pressing once will have one inverse phase.
4 Monitor
（V）
Monitor this contact
4. When defined as T, C, R or D, the value change is by pressing or to make the corresponding
M1840～M1871 ON (the client is required to write a plus/minus 1 program in the LADDER program) to achieve
this purpose.
Soft
key
0 1 2 3 4 5 6 7 8 9 T C D R SHIFT
×
M1840 M1841 M1842 M1843 M1844 M1845 M1846 M1847 M1848 M1849 M1850 M1851 M1852 M1853 M1854 M1855
Ø
M1856 M1857 M1858 M1859 M1860 M1861 M1862 M1863 M1864 M1865 M1866 M1867 M1868 M1869 M1870 M1871
