3-3
 General Timer/Counter Function Instructions
FUN
No.
Name Operand
Derivative
Instruction
Function descriptions

T nnn PV
General timer instructions (“nnn” range 0～255)

C nnn PV
General counter instructions (“nnn” range 0～255)
 Single Operand Function Instructions
 4
DIFU D To get the up differentiation of a D relay and store the result to D
 5
DIFD D To get the down differentiation of a D relay and store the result to D
 10
TOGG D Toggle the status of the D relay
 Setting/Resetting

SET D DP Set all bits of register or a discrete point to 1

RST D DP Clear all bits of register or a discrete point to 0
114 Z-WR D P Zone set or clear
 SFC Instructions

STP Snnn STEP declaration

STPEND End of the STEP program

TO Snnn STEP divergent instruction

FROM Snnn STEP convergent instruction
 Mathematical Operation Instructions
 11
(＋)
Sa,Sb,D DP Perform addition of Sa and Sb and then store the result to D
 12
(－)
Sa,Sb,D DP Perform subtraction of Sa and Sb and then store the result to D
 13
(＊)
Sa,Sb,D DP Perform multiplication of Sa and Sb and then store the result to D
 14
(／)
Sa,Sb,D DP Perform division of Sa and Sb and then store the result to D
15
(＋1)
D DP Adds 1 to the D value
16
(－1)
D DP Subtracts 1 from the D value
23 DIV48 Sa,Sb,D P Perform 48 bits division of Sa and Sb and then store the result to D
24 SUM S,N,D DP
Take the sum of the successive N values beginning from S and store
it in D
25 MEAN S,N,D DP
Take the mean average of the successive N values beginning from S
and store it in D
26 SQRT S,D DP Take the square root of the S value and store it in D
27 NEG D DP
Take the 2's complement (negative number) of the D value and store
it back in D
28 ABS D DP Take the absolute value of D and store it back in D
29 EXT D P
Take the 16 bit numerical value and extend it to 1 32 bit numerical
value (value will not change)
30 PID
TS,SR,OR,
PR,WR
PID operation
31 CRC MD,S,N,D P CRC16 checksum calculation
32 ADCNV PL,S,N,D Offset and full scale conversion
