Favero ASSIOMA PRO MX - Washer Use for Clearance Adjustment; Final Tightening and Torque Specification

9
If the distance is inferior
to 4mm, use one or two
washers (A1, A2).
Use only the washers
provided by Favero
Electronics.
See Fig. 8.
3. Tightening on the crank-arm
Finish tightening with a
torque wrench by applying a
force of 30-40Nm.
Turn counter-clockwise for
the left pedal (L), clockwise
for the right (R).
Make sure the pedal is correctly tightened before use.
Read carefully the information in the guarantee and
security manual provided within the box.
A1
A2
Fig. 8
Fig. 9
30-40Nm
15
Use a 15mm-open-end
wrench.
Don’t use spanners or
adjustable wrenches.
