1. PARTICULARS
The FENCING APPARATUS 07 (FA-07) is a multifunctional apparatus used for the sport of fencing.
1.1 Included and optional accessories
Accessories included with the FA-07:
• Carrying case;
• Infrared and cable-operated remote control;
• Power supply 90÷264Vac/12Vdc 2.5A, conforms to UL 60601-1 standards;
• 2 telephone cables 15m and 2.5m in length, with RJ-14 (6P4C) jacks for connection via the SERIAL DATA ports ;
• 2 telephone cables 10m and 1.3m in length, with RJ-10 (4P4C) jacks for connection to the remote control. The short cable
is more convenient for recharging the battery.
Optional accessories:
• Art.944 - Table Stand 96cm high for FA-07;
• Art.945 - Pair of 360° Tower-Lights for FA-07;
• Art.948 - Carrying case for Table Stand 96cm and Tower-Lights;
• Art.828 - Rechargeable Battery 12V/7Ah with connectors;
• Art.829 - Battery Recharger (for Art.828 battery);
• Art.856 - Power cable with clamps for connecting to a car battery (length: 3.5m);
• Art.880 - Doubler for SERIAL DATA.
1.2 Technical Data
• Size and weight of FA-07 (scoreboard): 55 x 35 x 9.5cm, 4.2kg
• Size and weight of infrared remote control: 14.3 x 5 x 2.3cm, 0.19kg
• Size and weight of carrying case: 60 x 40 x 13.5cm, 2.8kg
• Total weight of FA-07 with carrying case and included accessories: 8.1kg
• Operating temperature: 0..45°C
• Storage temperature: -20..+85°C
• Relative humidity: 10..90%
• Level of protection: IP32
• Remote control battery: 3.6V 600mA, Lithium-ion
• Battery recharge time: 7hrs max
1.3 Warranty
The warranty is good for 2 years from the date indicated on the purchase agreement and includes free repair of all defects
found in materials or in construction; the warranty does not cover delivery or transportation costs. The portable power supply
(Art.954) provided with the FA-07, and the optional battery (Art.828), are not covered by the warranty.
1.4 Power supply
• Power supply voltage: 12Vdc (10.6-14.5Vdc).
• Consumption: 0.5A typical,
0.85A max, without the Tower-Lights,
2.3A max, with both TOWER-LIGHTS connected and switched on.
1.4.1 Safety warning
WARNING: Supply power to the FA-07 exclusively by means of the power supply unit provided (Art.954) to ensure
that safety isolation requirements are met; otherwise supply power by means of a 12Vdc battery.
1.4.2 Battery power supply
We recommend using a lead-acid 12V battery. The battery listed in the catalogue (Art.828) enables uninterrupted use of the
FA-07 for 10-12 hours, while a 70Ah car battery lasts 120 hours. On the FA-07 graphic display panel the power supply voltage
is indicated and relates to the remaining life of the battery. When the battery’s voltage is 12.0V, only about 5-10% of its
capacity is available. We recommend recharging the battery after each use or, in any case, if the voltage is <12.5V
. We also
recommend recharging the battery at least every 6 months when not used for long periods, mainly due to the fact that if left to
run down, it will deteriorate and lose its power completely.
The battery’s positive pole must be connected to the number 2 contact of the power supply connector, otherwise the FA-07
will not switch on. If the FA-07 does not switch on after connecting it to a car battery, try inverting the connections to the
clamps.
