FBD 562 - Temperature Sensor Connector Location on Main PC Board

Temperature Sensor
Temperature Sensor Connector Location on Main PC Board
Temperature Sensor
Connector Location on Aux
Board
Temperature Connection Configuration
P24 P25 P26 JA26 JB26 JC26
562 Barrel 1 Barrel 2
563 Barrel 1 Barrel 2 Barrel 3
564 Barrel 1 Barrel 2
Jumper to JA26
Jumper to P26
Barrel 3 Barrel 4
1 2 3 4
Cold Pack
27
