Secondary lower power board
30
Beater Motor #4
Transformer
Beater Motor #4
SLOW-BLOW FUSES
From Contactor L1 & L2
From Transformer 12 & 24VAC
Auxiliary (AUX) Board
Control Signals to & from
Auxiliary (AUX) Board
DC Power Supply to
Auxiliary (AUX) Board
