INSTALLATION, OPERATION, AND SERVICE MANUAL

FOR THE

MODEL FBD550

FROZEN BEVERAGE DISPENSER

SPECIFICATIONS

DIMENSIONS

Width 17.0 inches (432 mm)

Depth 32.3 inches (820 mm)

Height (Standard Countertop Unit) 34.0 inches (864 mm)

Height (Optional Roll Around Unit/Stand) 68.0 inches (1727 mm)

WEIGHT

Shipping 395 pounds (179.2 kg)

Empty 318 pounds (144.2 kg)

Operational 345 pounds (156.5 kg)

WATER REQUIREMENTS

Minimum flowing pressure 30 PSIG (207.0 KPa)

Maximum static pressure 70 PSIG (483.0 KPa)

CARBON DIOXIDE (CO

2) REQUIREMENTS

Minimum pressure 70 PSIG (483.0 KPa)

Maximum pressure 75 PSIG (517.5 KPa)

NOTICE:

The information contained in this document is subject to change without notice.

FBD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMIT-

ED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE. FBD shall not be liable for errors contained herein or for incidental consequential damages in connection with the

furnishings, performance, or use of this material.

This document contains proprietary information which is protected by copyright. All rights reserved.

© Copyright 2006 by FBD, all rights reserved.

This manual supersedes FBD Manual 24-0276-0003, dated 01/31/05.

Revision: 10-25-06

FBD Part Number: 24-0276-0003

THIS DOCUMENT CONTAINS IMPORTANT INFORMATION

This manual must be read and understood before the installation and operation of this dispenser.

Check out the FBD web site:

www.fbdfrozen.com

FBD Partnership, LP

• P.O. BOX 18597. • SAN ANTONIO, TX 78218 USA •

• 210-637-2800 • FAX 210-637-2844 • www.fbdfrozen.com •

• FBD TECHNICAL SUPPORT • 1-866-323-2777 • TECHNICAL SUPPORT FAX 1-210-637-2832

Table of Contents

Questions and Answers

D
Dustin DavisDec 1, 2025
Why is the compressor on my FBD Dispenser not starting?
- A
  Ashley PierceDec 1, 2025
  If the compressor on your FBD Dispenser isn't starting, here's what you can check: 1. Ensure the correct start procedure is followed by pressing “Def”, then “Run” to start. 2. Check if “Run Beater” or “Def Beater” indicates a delay mode. 3. Verify pressure readouts are at 70-72 psi, and adjust regulators if necessary. 4. Test the start capacitor and start relay, and replace if necessary. 5. In Manual On/Off, briefly activate the “Compressor” (DO NOT RUN FOR MORE THAN 10 SECONDS!). Check voltage across contactor T1 and T2 for 220 volts. If no voltage, replace contactor. If the contactor does not energize, check voltage across contactor coil terminals for 24VAC. If voltage is present, replace contactor. 6. Test the relay board for 24VAC output and 5VDC input on the contactor relay. Re...
A
arnoldrebeccaAug 25, 2025
What to do if product does not flow freely from FBD Dispenser?
- Z
  Zachary BurtonAug 25, 2025
  If the product from your FBD Dispenser does not flow freely or doesn't flow at all, you can try the following: 1. Inspect the CO2 check valve and clean or replace it. 2. In “Manual On/Off”, energize the CO2 and solution solenoid and check for 24VAC at the coil. Clean or replace the solenoid, if necessary. 3. Run a defrost cycle. If necessary, open and close the dispensing valve several times or run warm water over the valve. 4. Check water/syrup flow rates and brix and adjust, if necessary. Check the Level Control setting and adjust if necessary. Check the Thaw/Freeze settings and adjust if necessary. Defrost the chamber, ensure it is filled to 90%, then press "Run".
R
Roger SullivanAug 27, 2025
Why is my FBD Dispenser chamber filling even when turned off?
- J
  jonescraigAug 27, 2025
  If the chamber of your FBD Dispenser continues to fill even when the unit is turned off, the issue might be: * Solution solenoid plunger sticking. * Solution solenoid energized. * Solution solenoid left “ON” in “Manual”. To resolve this: 1. In “Manual On/Off”, energize the solenoid and check for 24VAC at the coil. Clean or replace the solenoid, if necessary. 2. Test the solenoid relay on the relay board for 24VAC output and 5VDC relay coil input. Replace the Relay Board, if necessary. 3. In “Manual On/Off”, turn the solenoid off.
A
Amber KingAug 27, 2025
How to troubleshoot low water pressure in FBD Dispenser?
- E
  Evelyn NielsenAug 27, 2025
  To troubleshoot low or no water pressure in your FBD Dispenser: 1. Ensure the water is turned on and check for any line restrictions. 2. Verify that the CO2 is turned on and the "CO2 Press" readout is at 70-72 PSIG (482.6-496.4 KPa). 3. Check that the "H2O Pressure" readout is at 70-75 psi. Check the transducer and replace it if needed. 4. Check the water pump and replace it if necessary.
A
Andrea SmithAug 29, 2025
What causes a faulty tank pressure reading on FBD Dispenser LCD?
- D
  donna02Aug 29, 2025
  A faulty tank pressure reading on the LCD of your FBD Dispenser is caused by a pressure transducer failure. Check the transducer and replace it if necessary.
S
Sarah FarleySep 23, 2025
How to correct the clock if it shows the incorrect time on the FBD Dispenser?
- A
  allisoncampbellSep 23, 2025
  If the clock on your FBD Dispenser shows an incorrect time/date: 1. Change the clock settings. 2. Replace the clock battery on the upper board.
C
Catherine WalkerSep 17, 2025
What should I do if the LCD readout is garbled on my FBD Dispenser?
- C
  carterscottSep 17, 2025
  If the LCD readout on your FBD Dispenser is garbled or blank: 1. Press “CANCEL” several times. 2. Check L1 & L2 of the contactor for 220 VAC and pins 1 and 2 of the J5 plug on the lower board for +5 VDC. Install a Buck/Boost transformer or replace the lower board, if necessary.
W
Whitney BakerSep 18, 2025
What to do if keypad buttons will not function on FBD Dispenser?
- N
  Nancy CrossSep 18, 2025
  If one or more keypad buttons on your FBD Dispenser will not function: 1. Check for loose or incorrect connections of the cable connecting the Main Control (upper) board to the keypad. 2. Replace the keypad.
M
Mrs. Ann MoranSep 8, 2025
What does it mean when the LCD on my FBD Dispenser shows low line voltage?
- C
  cruzdanielSep 9, 2025
  A low line voltage reading on the LCD of your FBD Dispenser indicates: * Low voltage to the unit (below 215 volts). * Incorrect voltage offset. To resolve this: 1. Check the voltage at L1 & L2 of the contactor and at the wall receptacle. Install a Buck/Boost transformer if necessary. 2. Access the “Machine Settings” menu and adjust the voltage offset so the "Line Voltage" readout equals the L1 and L2 contactor voltage.
D
Dustin KiddSep 6, 2025
What causes a noisy condenser fan in FBD Dispenser?
- J
  Jennifer CombsSep 6, 2025
  A noisy condenser fan in your FBD Dispenser can be caused by: * The fan contacting the condenser, fan blade guard, or another part. * An unbalanced fan blade. * Loose fan bracket fasteners. To address this: 1. Remove the fan guard and adjust the fan up or down as required. Remove any obstructions as necessary. Reinstall the fan guard. 2. Remove the fan guard, slide the fan blade weights (on 3 blades) to balance the fan. Replace the fan if necessary. Reinstall the fan guard. 3. Tighten any loose fasteners.
