FBD 771 - 2 Specifications and Requirements; General Requirements; Electrical Requirements

77X INSTALLATION & OPERATION MANUAL
771/772/773/774 MODELS
4
2. SPECIFICATIONS AND REQUIREMENTS
2.1 General Requirements
†
12” (304 mm) with side or back open-air conditions, 36” (914 mm) in equipment alcove.
2.2 Electrical Requirements
* All pressure values are listed in the manual in PSIG (kPag). However, the pressure readouts will be shown as “PSI” or
“kPa” on the dispenser display depending on the setting selected for “DISPLAY UNITS” (see Section 7.10).
Requirement
Syrup Supply Pressure 70 - 72 PSIG* (483 - 496 kPag)
Water Supply Pressure
30 PSIG (207 kPag) Minimum Flowing Pressure
70 PSIG (483 kPag) Maximum Static Pressure
Gas Supply Pressure 70 - 72 PSIG (483 - 496 kPag)
Clearance
3” (76 mm) Sides and Back,
12”-36” (304 mm - 914 mm) Top
†
Refrigerant R404A
Requirement
Frequency 60 Hz
Operational Voltage 230 VAC ± 10%
Current
771 MFLV 20 A
772 20 A
772 MFLV 20 A
773 30 A
774 30 A
