6. Specification Performance Part
6.2 Module power consumption
Operating mode Operating parameters Average current
Broadcast mode
(0 dBm、Uart off)
100ms AD Interval 76.62uA
200ms AD Interval 42.35 uA
400ms AD Interval 20.98 uA
1000ms AD Interval 9.96 uA
LE Connection
Status
20ms Connection interval
Uart off
149 uA
20ms Connection interval
Uart on
287 uA
300ms Connection interval
Uart off
10 uA
300ms Connection interval
Uart on
242 uA
6.3 Time parameter
Type Min. Type. Max. Description
Power-on time 230ms Enable UART response time
Wake up time
200ms The UART sends the wake-up data,
and then starts to calculate
6.4 Data transfer rate
Baudrate Pack size
Pack
interval
Bluetooth
connection
interval
Reporting
method
Maximum
transfer rate
115200 182 16ms 15ms Notify 11375 Byte/s
