FEC AM-1017 - Chapter 2 MSR; Finger Print Reader; RFID; i-Button Installation

System Manual
8
C
C
h
h
a
a
p
p
t
t
e
e
r
r
2
2
MSR / Finger Print Reader/ RFID / i-Button Installation
1. Remove the plastic cover
at the back of Touch
Display Module
2. Insert the MSR / RFID /
Finger Print Reader / I-
button Module into USB A-
Type Connector. Fix the
Touch Display Module with
one screw.
3. Make sure the USB connected and screw is fastened well.
4. If you are looking for the detail Utility of MCR, Finger Print Reader, I-button Reader,
RFID Reader, please contact FEC’s FAE.
