SMOOTH MOVEMENT
Figure 35 - Check Dropout Coupling Fit
9. Inspect the exible coupling radial and axial
t. It should have little or no movement and
be slightly more loose than the motor shaft
t. It should also slide smoothly on and o
the pump shaft.
10. Once proper exible coupling t on both
shafts has been obtained, remove the drop-
out coupling and proceed with Initial Pump
Alignment.
NOTES: The dropout coupling will not be need-
ed until the Final Pump Alignment - No Motor
Adapter procedure.
Pump Assembly Continued
NO
MOVEMENT
NO
MOVEMENT
NO
MOVEMENT
NO
MOVEMENT
