Item Part Description
BDK
Balance
Disc Kit
MSK
Mechanical
Seal Kit
MSK HP
Mechanical
Seal Kit HPSC
SBK
Stage
Bushing Kit
DFK
Di󰀨user Kit
IMK
Impeller Kit
SHT
Shaft Kit
POK
Pump
O-Ring Kit
SOK
Stage
O-Ring Kit
FCK
Flex
Coupling Kit
ALK
Alignment
Kit
DLK
Drain
Line Kit
1 Shipping plug * 2 Socket head cap crews * 3 Mechanical seal cartridge * 4 Mechanical seal O-Ring
X X X X
5 Mechanical seal X X
6 Shaft washer X X
7 Mechanical seal retaining ring X X
8 Wear ring O-Ring X X 9 Wear ring anti-roll pin X
10 Wear ring X
11 Wear ring retaining ring X
12 Impeller keys X 13 Impeller set screw X 14 Impeller X 15 Set screw retaining ring X 16 Stage bushing anti-roll pin X 17 Stage bushing X 18 Stage bushing O-Ring X X 19 Stage bushing retaining ring X 20 Bearing holder * 21 Bearing holder O-Ring X X
22 Balance disc washer X
23 Balance disc key X
24 Balance disc X
25 Shaft nut X 26 Shaft nut set screws X
27 Pump shaft X 28 Shaft key X X 29 Assembled ex coupling X 30 Di󰀨user/ inlet O-Ring X X X X X
31 Di󰀨user housing (bowl) X 32 SS shim set X 33 Alignment pins X 34 HP shaft bushing/ mechanical seal cartridge O-ring X 35 HP shaft bushing X 36 HP shaft bushing anti-roll pin* 37 Drain line connector X 38 Bearing drain line X 39 Drain line elbow (MSD-160/200 only) X
40 Throttle nipple (HP units only) X 41 Outboard wear ring (MSD-270 0nly) X
42 Split collar set (MSD-270 0nly) X 43 Countersunk cap screws (MSD-270 0nly) X 44 Stage bushing washer (MSD-270 0nly) X 45 Inboard wear ring (MSD-270 0nly) X
* Not Included in any kit. Can be purchased separately.
