Fedders R407C - Page 13

E
E
E
E
1
H
1
H
F
F
F
F
C
C
C
C
4
4
4
4
1
1
2
2
8
8
4
4
N
N
N
N
Item
6
6
6
6
No.
Description
Service Part #
G
G
G
G
-----CHASSIS ASSEMBLY-----
1 Front Grille 35-24-05150-001 1 1 1 1
2 Front Panel (painted),Neuter 35-24-05010-083 1 1 1 1
3 Fan Blade 37-24-01010-001 1 1 1 1
4 Fan Motor 35-24-90000-001 1 1 1 1
5 Mesh-Panel (securing) 35-08-02000-001 3 3 3 3
6 Rear Post (painted) 35-24-05050-081 1 1 1 1
7 Top Cover (painted) 35-24-05080-083 1 1 1 1
8 Side Panel (painted) 35-24-05060-081 1 1 1 1
9 Service Cover 35-24-05140-001 1 1 1 1
10 Compressor Blanket 35-05-00190-001 1 1 1 1
11 Motor Mounting Bracket (Painted) 35-24-05090-081 1 1 1 1
12 Partition (Asm with foam seal) 37-24-08130-001 1 1 1 1
44 Wiring Diagram (C/O) 35-24-00100-003 1 -- 1 --
44 Wiring Diagram (H/P) 35-24-00120-003 -- 1 -- 1
45 Mounting Bracket Reinforced 37-24-05010-081 2 2 2 2
-----REFRIGERANT ASSEMBLY-----
13 Base Pan Asm. (1-48 Frame) 35-24-08010-084 1 1 -- --
Base Pan Asm. (Bristol) 35-24-08010-081 -- -- 1 1
(include base pan and mounting
legs - painted)
14 Service Valve Plate (painted) 35-24-05100-083 1 1 1 1
15a 3-Way Service Valve, 5/8" 37-24-06010-003 1 1 1 1
15b 2-Way Service Valve, 3/8" 37-24-06020-002 1 1 1 1
MODEL NUMBER
FEDDERS
LARGE SPLIT UNIT
OUTDOOR CONDENSER UNIT
(R407C)
B8
