SECTION IB-2A-210
INSTALLATION & OPERATION INSTRUCTIONS
TYPE PSE PAD-MOUNTED SWITCHGEAR
NOVEMBER 2017, REV 4.2
PAGE 14
Maintenance
Federal Pacific Pad-mounted Switchgear does not normally require routine
mechanical or electrical maintenance. However, the following are some
recommendations for enhancing continued service of the equipment.
1. Yearly mechanical exercising of the switch is recommended.
The switchgear must be completely de-energized from all sources
before any attempt is made to enter switchgear.
2. Check for cleanliness generally, but particularly for accumulation of
any foreign material on insulators.
Do not put grease on switch probe or puffer.
3. If the switch is closed into a short circuit within the making capacity
rating and the short circuit is cleared by circuit breakers or fuses,
the switch should not sustain damage that will require major repairs.
However, the switch should be inspected before returning to service
to determine switch condition.
Optional Features
Standard options may have been supplied that best serve the customer’s
needs and operating practices. These are listed below and, if included
will be identified by corresponding suffixes to the catalog number.
Base Spacer (option suffixes A2 through A9; AS for stainless steel base
spacers) Non-compartmented or compartmented.
• Fuse Storage Hooks (option suffix E1 through E5)
• Finish color (option suffix F3)
• Stainless steel enclosure exterior (option suffix F4)
• Hex-head security bolts (option suffix H)
• Key interlocks (option suffixes K1 through K4)
• Cable supports (option suffixes T3 and T4)
• Fault indicators (option suffixes T6 and T7)
• Copper bus (option suffix C)
WARNING
CAUTION
