Chapter 7: Testing the Convergence Network
SmartSiren Platinum Convergence Network
53
Figure 7.8 LED programming indicators on the control head
SLIDE SWITCH LEDs: LEDs above the slide switch glow
when the system is on (1=green, 2=amber, 3=red). The
LED brightens above the position in which the slide switch
is placed.
SmartSiren® LEDs: LEDs mimic these active
SignalMaster patterns: Left, Right, Center-Out,
or Warn patterns 1 to 4. They also indicate
when a programmed feature of the key head is
active (see “Setting Control Head Options” on
page 43.)
Button LEDs: All buttons on the control
head glow when the system is on. Pressed
buttons blink to indicate that the function
they control is active.
The control head legends in the illustration are for a typical conguration. The SSP3000B/SSP2000B kit
includes additional legends. All buttons are programmable. For instructions for programming the control head,
see the “SSP3000B Control Head Conguration Software Manual” (doc. no. 2562418).
