8
2）Indicator mark
A.1 A.2 A.3 A.4 A.5
A.1 Read the operating manual.
A.2 Keep the bystanders away, risk of projections.
A.3 Do not touch the rotating parts while operating.
A.4 Toxic gases; do not operate inside the house.
A.5 Please wear protective gloves; pay more attention to your hands
and feet to avoid injury.
A.6 When repairing, please pick up the spark plug and repair it
according to the operation manual.
A.7 Caution: The engine is hot.
A.8 Wear glasses and earplugs to protect the operator.
Fig.1 A.6 A.7 A.8
———————————————————————————————————————————————————————————————
3）Control mark
Fig.3
DY1P70FA
throttle mark
Fig.4.1 △Self-propelled drive tag
Fig.4.2 △Roller brush drive mark
———————————————————————————————————————————————————————————————
4）Parameter mark
Fig.5.1 Self-propelled parameter marker Fig.5.2 Hand push parameter marker
———————————————————————————————————————————————————————————————
5）LOGO mark
Fig.6
