19
5. Reasonable work area
●Ground and lawn covered by fallen leaves. (See Fig 27-1, 2)
Fig.27-1 Fallen leaves on the lawn Fig.27-2 Fallen leaves on the lawn
●Ground and lawn with more leaves(Please see the picture 28-1, 2）
Fig.28-1 Fallen leaves on the road surface Fig.28-2 Scattered garbage on the road
5） △self-propelled operation instructions
1. After starting the machine, first close the roller brush drive lever and then close the self-propelled drive lever. (See Figure 29-1, 2, 3)
Fig.29-1 Pull rod closing direction Fig.29-2 Clamping lever Fig.29-3 Wheel rotation direction
6） △Auxiliary hose instructions for use
6）-1. Auxiliary hose function—Vacuum function
1. Please assemble the auxiliary hose according to the steps in the assembly instructions "Assembly Step 6" Auxiliary Hose Assembly" (page 9-10).
2. Insert the suction port baffle into the suction port。（ see fig 30-1、2）
Fig.30-1 Insert baffle Fig.30-2 The baffle is inserted into place
