3. Start the machine，Point the hose mouth at the trash。（ see fig 31）
●Note: When loading and unloading the hose, please turn off the engine first.
●Note: The suction port baffle is only used when the auxiliary hose is vacuumed.
Fig.31 Using a hose
6）-2. Auxiliary hose function—Telescopic function
1. Telescopic tube can adjust the height of different handle positions
2. Push the Lock with your thumb while adjusting the handle position forward or backward. (See Fig 32-1, 2)
Fig.32-1 Push open the lock Fig.32-2 Adjust the telescopic height
6）-2. Auxiliary hose function—Blow function
1. Close the rear cover（see fig 33-1、2、3）
Fig.33-1 Close the rear cover Fig.33-2 Close completely
