classic-pro Installation ID CPR50.10-E/-RE
FEIG ELECTRONIC GmbH Page 32 of 39 M90701-1de-ID-B-FCC.doc
E N G L I S H
8.1.4. Connection with External Powered Supply
Ethernet
ID CPR.IO
ID CPR50.10-E
Door Contact
X3
4
3
5
6
1
2
+
-
NOTICE:
• Use only regulated power supply’s.
• Reversing the polarity of the supply voltage may destroy the device.
• Supply voltages outside the specifications may destroy the device.
• If switching power supplies are used with the module, be sure that there is adequate fil-
tering.
• Noise from the power supply can result in a reduction of the read/write range of the
module.
