VEK MNH Operating Manual v1.3 en
when loop 1 is covered (factory setting for output 1)
when loop 2 is covered (factory setting for output 2)
for travel direction A (factory setting for output 1)
for travel direction B (factory setting for output 2)
for both travel directions
Tab. 25: Assigning the outputs
1
when detuning loops for larger approach thresholds and when direction detection is switched off
2
when direction detection is activated
3
for dual-channel variants
11.9 Setting output switching time (impulse time)
The switching time for the outputs can be defined in impulse signal mode.
Set impulse duration
The default impulse duration is 200 ms. This can be changed in the Detector Tool in increments of 100
ms.
when the loop is driven past (factory setting)
when the loop is freed up
Tab. 26: Output impulse time
11.10 Setting output times (output time behaviour)
The switch-on delay, the switch-off delay and the minimum signal duration for the output signals can be set
in the range from 0 to 25,500 ms in increments of 100 ms.
Switch-on delay with short loop coverage
If the loop becomes free before the switch-on delay has expired, no signal is output.
Settings with the Detector Tool
The settings can only be changed with the Detector Tool.
