1270P MONITOR
PRINTED CIRCUIT BOARD ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0024997001 RES CF 1/4W 5% 100k LL R9 R17-19
4 0031819001 RES MF 1/4W 1% 1.82k LL R1-4
4 0031818001 RES MF 1/4W 1% 18.2k LL R5-8
1 0015718001 RES MF 1/4W 1% 1.00k LL R40
1 0030737001 RES CF 1/2W 5% 5.6ohm LL R28
1 0037169001 RES CF 1/2W 5% 1.8k LL R50
2 0039189000 RES WW BT 7W 10% 390ohm R51-52
1 0050573000 XLR CONNECTOR FEMALE GOLD J1
3 0025751003 XSTR NPN 2SC2362K/2SC2389STPS Q3 Q6 Q8
1 0028114000 XSTR NPN TIP142 TO-218AC Q1
3 0025752003 XSTR PNP 2SA1038STPS Q4-5 Q7
1 0028115000 XSTR PNP TIP147 TO-218AC Q2
INPUT (CHASSIS) ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0055728000 PCB ASSY 1270 CROSSOVER
1 0055715000 PLATE INPUT 1270 MONITOR
2 0021956000 JACK PHONE OPEN CIRCUIT 11
4 0025804000 STANDOFF 6-32x1/2 RND AL
8 0031184000 SCRW M6-32x1/4 PHPS BLX ITLW
2 0016436000 WSHR LCK INTL 3/8x.687x.035 NI
2 0031153000 WSHR FLAT 3/8x.614 NI
2 0016352000 NUT HEX 3/8-32x3/32 TK NI
BAFFLE (CAB) ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1.18 0047792000 PLYWOOD BALTIC BIRCH 5/8" SF
0.174 0040046000 CARPET BLACK SY
4 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
END ITEM ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0055598000 BAFFLEBOARD ASSY 1270 MONITOR
1 0055376000 CABINET 1270 MONITOR
1 0055740000 SPKR 10" 8 OHM COAXIAL
1 0055741000 DRIVER HORN PIEZO
1 0055742000 GASKET HORN THROAT
1 0055743000 INPUT ASSY 1270 MONITOR
1 0051494000 POLY DAMPING
1 0055618000 GRILLE 1270 MONITOR
1 0055744000 LOGO ELLIPTICAL RED "F"
2 0055732000 PUSH NUT 1/8" POST
4 0029677000 SCRW SMA 6x1 THP BLX
To Next Page
