BXR 100 Specifications
Part Number:
Type Specification:
Power Requirements:
POWER AMPLIFIER SECTION:
Power output:
Rated load impedance:
Distortion at 100 watts:
Sensitivity:
Input impedance:
DELTACOMP™ range:
PREAMP SECTION:
Input impedance:
Sensitivity for 100 W:
GAIN and VOLUME at
maximum, all tone
controls at “0” detent,
no enhancement activated.
Shelving tone controls:
Graphic Equalizer:
PHYSICAL SPECIFICATIONS:
Height:
Width:
Depth:
Weight:
Speaker:
120V Version: 22-4401
230V Version: 22-4461
PR 233
120V Version: 120VAC, 60 Hz, 2.4 A Max.
230V Version: 230VAC, 50 Hz, 1.25 A Max.
100 watts R.M.S.
8 Ohms
Less than .1% @ 1kHz, below compression;
less than 1% @ 1kHz, maximum compression.
1.03 volts R.M.S.
22 k Ohms
20 db
Input 1 - Greater than 420k Ohms (typically
greater than 1 megaohm in the passband)
Input 2 - 136k Ohms
Input 1 - 13mV
Input 2 - 26mV
LOW +/- 12 dB at 60 Hz
HIGH +/- 12 dB at 10kHz
+/- 12 dB at 80, 150, 300
570, 1.1k, 2.1k, and 4kHz
25-1/2 inches (64.8 cm)
21-1/2 inches (54.6 cm)
13-1/2 inches (34.3 cm)
64 lbs. (29.1 kg)
15” Fender Special Design (P/N 040580)
WARNING: NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
