Page #6 background imageLoading...
Page #6 background image
CHAMPION™ 30 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
6
PARTS LIST:
MAIN – PCB ASSEMBLY
(continued)
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0057312004 PCB ASSY CHAMPION 30 DSP
1 * ** PCB FAB CHAMPION 30 DSP
REF 0057314000 SERV. DIA. COMB. CHAMP 30 DSP
2 0038689001 CAP AE AX .47uF 100V 20% C8-9
2 0028463003 CAP AE RDL 10uF 50V 20% C30 C64
2 0028458003 CAP AE RDL 1uF 50V 20% C25 C41
2 0028459003 CAP AE RDL 2.2uF 50V 20% C42-43
2 0033607000 CAP AE RDL 2200uF 35V 20% C35-36
8 0028467003 CAP AE RDL 22uF 50V 20% C3 C11 C26 C29 C39-40 C55 C63
1 0028460003 CAP AE RDL 4.7uF 50V 20% C44
2 0028471003 CAP AE RDL 47uF 50V 20% C37-38
2 0039255001 CAP CA 10pF 100V LL C10 C16
2 0051457003 CAP CD 100pF 500V 5% C24 C69
3 0051458003 CAP CD 470pF 500V 10% C7 C47 C54
1 0051459003 CAP CD 560pF 500V 10% C17
2 0051409003 CAP CD 68pF 500V 5% C65-66
8 0034788003 CAP CR .1uF 50V 20% .2" LS C31 C33 C46 C51 C59-62
2 0020867002 CAP CD 330pF 1000V 10% C52 C68
1 0053860000 ** CAP MPF .1uF 250VAC 20% C58
7 0027278003 CAP MPF .1uF 63V 10% C14 C28 C48-50 C56-57
2 0033579003 CAP PFF RDL .0015uF 100V 10% C27 C53
2 0033580003 CAP PFF RDL .0022uF 100V 10% C13 C32
1 0033581003 CAP PFF RDL .0033uF 100V 10% C21
3 0033583003 CAP PFF RDL .0047uF 100V 10% C1-2 C22
3 0033590003 CAP PFF RDL .022uF 100V 10% C12 C19 C45
4 0027264003 CAP MPF .01uF 100V 10% C67 C70-72
2 0033591003 CAP PFF RDL .033uF 100V 10% C5-6
5 0033592003 CAP PFF RDL .047uF 100V 10% C4 C18 C20 C23 C34
1 0033596003 CAP PFF RDL .068uF 100V 10% C15
3 0037324000 CONTROL SNAPIN 100k 30C R13 R25 R32
GAIN, (DR) VOLUME, TREBLE
2 0038656000 CONTROL SNAPIN 10k B R45 R81
FX SELECT, FX LEVEL
1 0040552000 CONTROL SNAPIN 250k 30C
R35 BASS
1 0037323000 CONTROL SNAPIN 50k 15A R22
VOLUME
1 0034719000 CONTROL SNAPIN 50k B R31
MID
7 0064089001 DIODE 1N4003 LL D13-16 D22-23 D28
10 0006260001 DIODE 1N4448 SIGNAL LL D1-2 D5-7 D20-21 D24-26
2 0009165001 DIODE ZEN 1N4744A 15V 1W 5% D17-18
1 0031019001 DIODE ZEN 1N5245B 15V 5% LL D27
10 0025802000 FSTN TAB MALE .250x.032 PCB MT P3-5 P7-11 P13-14
3 0026000001 FSTN TAB MALE PCB MT .187x.032 P1 P6 P12
2 0051094003 ** FUSE CLIP PCB 5mm @ F1
1 0057350000 HDR .1 CTR 8x2 CKT SQ PIN P2
1 0057804000 HEATSINK PLATE LM3876 @ U8
1 0050849000 HEATSINK PCB LEVEL 576012U @ U7
1 0028120000 IC 4053B TPL 2 CHAN ANLG SW U9
5 0031611000 IC OP-AMP DUAL PC4560 U2-5 U10
1 0016795000 IC OP-AMP DUAL TL072 U1
1 0057769000 IC POWER AMP 56W/MUTE LM3876T U8
1 0041812000 IC REGULATOR +5V MC7805CT U7
3 0051658000 JACK MONO R/A J1-3
INPUT1, INPUT 2, FOOTSWITCH
1 0055595000 JACK STEREO R/A w/SL SHUNT J4
HEADPHONE
3 0049948000 LED RED LONG LEAD LUMEX D3-4 D12
DISTORTION, DRIVE STATUS
1 0055812000 LED TULIP ASSEMBLY D19
POWER
1 0027869001 RES CF 1/2W 5% 470ohm LL R61
