CHAMPION™ 30 DSP
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY on page 4.
Unique Fender® part. Order directly from the Fender® dealer Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
9
PARTS LIST:
CHASSIS ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4 0053480000 WASHER, FLAT .442x.692 NI @ J1-4
1 * CHASSIS CHAMPION 30 DSP AMP
1 0057957000 WIRE SET CHASSIS DOM. CHAMP 30 DSP 120V ONLY
- 0057956000 WIRE SET CHASSIS EXP. CHAMP 30 DSP 100, 230-240V ONLY
7 0054419000 KNOB ROTARY 180 SS W/CHR INS
@ CONTROLS
1 0057347000 KNOB ROTARY W/CHR INS PNTR 180
@ FX SELECT
1 0054642000 ** CONNECTOR IEC SNAP IN
1 0054798000 JEWEL ASSY LED @ FRONT PANEL
1 0031625000 NUT HOLDER PILOT LIGHT 1/16-27 @ JEWEL ASSY LED
1 0057264000 PANEL FRONT CHAMPION 30 DSP
1 * PANEL REAR CHAMPION 30 DSP
4 0069393000 NUT 6-32 HEX EXT LOCK @ PWR XFMR
PARTS LIST:
CABINET ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0027846000 HANDLE 9.25" NO LOGO
2 0025395000 HANDLE CAP 1 HOLE NI (DWG17420) @ HANDLE
1 0032524000 INSERT HANDLE @ HANDLE
6 0021972000 NUT T 10-32x3/4 STR 3 PRNG BLX @ HANDLE, GRILLE
4 0026566000 CORNER 2 HOLE w/TAB NI
2 0026568000 CORNER 3 HOLE NI
2 0022244000 SCRW M 10-32x1-1/8 OHP NI @ HANDLE
14 0026571000 SCRW SMAB 8X5/8 THP NI @ CORNERS, FEET
0.014 0027648000 TAPE ALUM 6"x60YDS
0.194 0029085000 VELCRO STRIP LOOP 1.5"wd BLK @ FTSW LOOPS
0.194 0029086000 VELCRO STRIP HOOK 1.5"wd BLK @ FTSW LOOPS
4 0029323000 FOOT RUBBER 1.0 DIA SMALL
0.91 0026570000 TOLEX "BRAVURA BLACK"
PARTS LIST:
END ITEM ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
2 0018113000 SCRW SMA 4x1/2 OHP BLX @ FENDER NAMEPLATE
4 0026577000 SCRW M 10-32x1 PHP BLX @ SPEAKERS
2 0026800000 SCRW SMAB 8x1-3/4 OHP BLX @ GRILLE
6 0029527000 WSHR FNSH 8-5/8 FLNGD BLX WX @ GRILLE AND CHASSIS SCREWS
1 0029906000 NAMEPLATE FENDER GENERIC SMALL @ GRILLLE
4 0036199000 SCRW M 8-32x1-3/16 OHP BLX CP @ CHASSIS
1 0036502000 SPKR 10" 8 OHM (099-4810-003)
1 0057764000 CAB ASSY CHAMPION 30 DSP
1 0057315000 MANUAL OWNERS CHAMPION 30 DSP
1 0047248000 ** CORD PWR W/IEC CONN DOM 120V DOMESTIC
- 0053997000 ** CORD PWR W/IEC CONN 100V JPN 100V JPN
- 0047250000 ** CORD PWR W/IEC CONN 240V AUST 240V AUST
- 0047249000 ** CORD PWR W/IEC CONN 230V UK 230V UK
- 0047251000 ** CORD PWR W/IEC CONN 230V EUR EUR & ROK
- 0057674000 ** CORD PWR W/IEC CONN 230V ARG 230V ARG
