Fender Deluxe 112 Plus - Chassis Assembly Parts; Footswitch Assembly Parts; Cabinet Assembly Parts

DELUXE 112 PLUS
PRINTED CIRCUIT BOARD ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 016742 XSTR PNP 2N4403 TO-92 Q9
2 028115 XSTR PNP TIP 147 TO-218AC Q2,11
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048879 CHS ASSY DELUXE 112 PLUS (COMPLETE CHASSIS 120V)
1 021709 BUSHING SR .437X.062X 13/32 BLK (@ SPEAKER CABLE)
1 026116 BUSHING SR .500X.063X7/16 BLK (@ REVERB CABLE)
1 026038 BUSHING SR .625X.062X37/64 BLK (@ POWER CABLE)
1 010401 BUSHING SR .625X.125X37/64 WHT (@ POWER CABLE 230/240V)
1 026527 CABLE ASSY PWR 120V .187 TABS (POWER CABLE 120V ONLY)
1 048465 CABLE ASSY PWR .187 TAB 100V (POWER CABLE 100V ONLY)
1 026528 CABLE ASSY PWR 230V .187 TAB (POWER CABLE 230V ONLY)
1 036479 CABLE ASSY PWR AUST .187 TABS (PWR CABLE AUSTRALIA ONLY)
1 040992 CABLE ASSY PWR 5A U.K. .187 TAB (PWR CABLE UNITED KINGDOM)
1 048874 CHS DELUE 112 PLUS (RAW CHASSIS)
1 028560 END BELL XFMR 85W (TRANSFORMER MOUNT
1 031726 HEATSINK BAR M-80 (COUPLER TO CHASSIS)
10 026402 KNOB POINTER BLACK
4 028591 NUT ACORN 8-32 (TRANSFORMER MOUNT)
1 048875 PANEL FRONT DELUXE 112 PLUS
1 048876 PANEL REAR DELUXE 112 PLUS
1 038900 SCRW TF 6-32X1*4 PHP ZI (@ GROUND LUG)
2 028937 SCRW TF 6-32X5/8 PHP ZI TAPTYT (PCB TO CHASSIS MOUNT)
5 028500 SCRW TF 8-32X3/4 HWH SLTD ZI (HEATSINK TO CHASSIS MOUNT)
2 025936 STANDOFF NYLON PCB SNAPIN 3/8” (PCB MOUNT)
1 025935 SWITCH DPST .187 TAB (DOM) (POWER SWITCH)
4 030007 WSHR LCK INTL 8X.330X.02 ZI (TRANSFORMER MOUNT)
1 027668 XFMR PWR 120V 85W (120V DOMESTIC ONLY)
1 039357 XFMR PWR EXP DELUXE 112 (100V/115V/230V/240V)
FOOTSWITCH ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 028/122 FOOTSWITCH 2 BTN REVERB F/LOGO (COMPLETE FOOTSWITCH)
2 006260 DIODE 1N4448/1N914B SIGNAL CR1,2
1 037036 JACK PHONE PCB MONO CA PREMIUM J1
2 028039 LED RED 5X5MM SLB-55VR3 LD1,2
2 028714 SWITCH PUSH SPDT S1,2
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 041485 CAB ASSY PERFORMER 650 (CABINET ONLY)
1 022491 CLAMP CABLE NYL SCRW MNT 5-16 (@ REVERB CABLE)
4 026566 CORNER 2 HOLE W/TAB NI
2 026568 CORNER 3 HOLE NI
4 019276 GLIDE CAB 1.24X.335 NI (NO INSERT)
1 040051 GRILLE ASSY DELUXE 112 (GRILLE ONLY)
1 027846 HANDLE 9.25” NO LOGO (RUBBER ONLY, NO INSERT)
2 019279 HANDLE CAP 2 HOLE NICKEL (HANDLE MOUNT)
4 019275 INSERT GLIDE CUSHION 1.27 DIA (RUBBER ONLY)
1 032524 INSERT HANDLE (SPRING STEEL)
1 011298 NAMEPLATE FENDER SMALL (LOGO)
8 021972 NUT T 10-32X3/4 STR 3 PRNG BLX (SPEAKER/HANDLE MOUNT)
1 028055 REVERB UNIT 800 OHM 8EB2C1B DN (PAN)
4 026577 SCRW M 10-32C1 PHP BLX (SPEAKER MOUNT)
4 022244 SCRW M 10-32X1-1/8 OHP NI (HANDLE MOUNT)
6 036199 SCRW M 8-32X1-3/16 OHP BLX CP (CHASSIS MOUNT)
5 029828 SCRW PB 8X3/4 PHP ZI (REVERB PAN MOUNT)
2 018113 SCRW SMA 4X1/2 OHP BLX (LOGO MOUNT)
2 011678 SCRW SMA 8X1-1/2 OHP BLX (GRILLE MOUNT)
10 026571 SCRW SMA 8X1/2 THP NI (CORNER MOUNT)
4 026625 SCRW WOOD 8X1 FH (GLIDE MOUNT)
