DELUXE 112 PLUS
CABINET ASSEMBLY (CONT)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
6 029527 WSHR FNSH 8-5/8 FLNGD BLX WX (CHASSIS MOUNT)
MISCELLANEOUS
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 048877 MANUAL OWNERS DLX 112 PLUS
1 048871 SCHEM REDU DLX 112 PLUS W/ SERV
