Fender Pinwheel - Page 2

6
19
23
1
3
4
17
13
12
11
7 8
1. Bypass Footswitch
2. Right Output Jack
3. Jewel Indicator
4. Left/Mono Output Jack
5. Level
6. Drive
7. Tone
8. Ramp
9. Fast
10. Rate LED
11. Slow
12. Exp/FS Input Jack
13. Sensitivity
14. Sensitivity LED
15. Right Input Jack
16. Mode Switch
17. Left/Mono Input Jack
18. Slow/Fast Footswitch
19. LED Kill Switch
20. Voicing Switch
21. Dynamics Switch
22. FS Select Switch
23. DC Power Connector
20 21 22
5
18
2
LEDs
9V DC
INPUT
VOICING DYNAMICS FS SELECT
THE PINWHEEL
LEVEL SENS
DRIVE FAST
MODE
1
2
3
SLOW
BYPASS SLOW/FAST
(BRAKE)
9 10
TONE
RAMP
16
14
15
