Page #2 background imageLoading...
Page #2 background image
1. Bypass Footswitch
2. Jewel Indicator
3. Output Jack
4. Blend Knob
5. Tone A
6. Gain A
7. Blend/Series Switch
8. Bass Boost Switch
9. Tone B
10. Gain B
11. Level Knob
12. Input Jack
13. Low Battery Indicator
14. LED Kill Switch
15. DC Power Connector
PUGILIST DISTORTION
BLEND
SERIES
BASS
BOOST
5
1
4
2
3
12
11
10
BLEND
A B
TONE A GAIN A TONE B GAIN B
LEVEL
14
15
LEDs
9V DC
INPUT
6 7 8 9
13

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fender Pugilist Distortion and is the answer not in the manual?

Fender Pugilist Distortion Specifications

General IconGeneral
TypeDistortion
Inputs1 x 1/4"
Outputs1 x 1/4"
BypassTrue Bypass
Power Source9V DC power supply (not included)
Dimensions2.5" x 4.9" x 2.5"
