TBP-1
®
™
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
11
PARTS LIST:
FOOTSWITCH ASSY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 0028895000 CABLE ASSY FTSW RT ANG 12'
1
*
HOUSING FTSW 4 BUTTON
1
*
HSG END CAP LEFT FTSW
1
*
HSG END CAP RIGHT FTSW
8
*
SCRW SMB 6x3/8 PHP BLX @ end caps
1
*
NUT HEX 12mmx1mm NI @ J1
4
*
WSHR NYL .485x.775x.150 TK @ S1-4
1
*
PLATE FTSW 4 BTN TBP-1
1
*
PCB ASSY,FTSW 4 BTN PRO TUBE
1
*
PCB FAB FTSW 4BTN PROTUBE AMPS
4
*
DIODE 1N4448 SIGNAL D1, D4, D6, D9
2
*
DIODE ZEN 1N5223B 2.7v 5% D2, D7
4
*
LED RED 5x5mm SLB-55VR3 D3, D5, D8, D10
4
*
SPACER RND NYL .147x.250x.780 @ D3, D5, D8, D10
4
*
SWITCH PUSH SPDT S1-4
1
*
JACK PCB MONO CA(099-0912-000) J1
Service Diagram List
Service Diagram (Schematic) ............TBP-1
Service Diagram (PCB Assembly) ............TBP-1
Chassis Assembly ............TBP-1
End Item Assembly ............TBP-1
Assembly ............4-Button Footswitch
