TBP-1
®
™
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
7
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
1 006471200x
**PCB ASSY TBP-1
REF 0064710000 SVC DIAG COMB TBP-1
1
*
PCB FAB TBP-1
2 0050687000 CABLE JMPR 6 CKT .156 ROUND PW1-2
2 0054303000 CABLE RIBBON 10 CKT 7.5" PW3-4
1 0037805000 CABLE RIBBON 6 CKT 2-1/4" PW5
8 0028459003 CAP AE RDL 2.2uF 50V 20% C26-28 C49-50 C58 C83-84
22 0028467003 CAP AE RDL 22uF 50V 20% C7 C18 C21 C30 C36-42 C52-53 C57 C60
+ C63 C72-73 C82 C119-120 C139
1 0036954003 CAP AE RDL 22uF 63V 20% C98
3 0054206000 CAP AE RDL 47uF 350V 20% 85'C C107-109
2 0028471003 CAP AE RDL 47uF 50V 20% C2 C15
4 0028474003 CAP AE RDL 100uF 25V 20% C86 C117-118 C140
2 0028494000 CAP AE RDL 1000uF 35V 20% C111-112
1 0051445003 CAP CD 22pF 500V 5% C56
9 0051408003 CAP CD 47pF 500V 5% C5-6 C47-48 C51 C59 C70-71 C85
1 0051405003 CAP CD 120pF 500V 5% C14
2 0051960003 CAP CD 180pF 500V 10% C19 C22
19 0051406003 CAP CD 220pF 500V 10% C8-9 C29 C43-46 C61-62 C64-65 C69
+ C74-77 C87-89
1 0020917000 CAP CD 250pF 1000V 10% C10
1 0039261001 CAP CA 330pF 100V LL C81
22 0034788003 CAP CR .1uF 50V 20% .2" LS C113-116 C121-138
2 0027255003 CAP MPF .001uF 100V 10% C1 C90
2 0027259003 CAP MPF .0033uF 100V 10% C32-33
1 0027260003 CAP MPF .0039uF 100V 10% C80
1 0027261003 CAP MPF .0047uF 100V 10% C96
1 0027262003 CAP MPF .0068uF 100V 10% C31
3 0027265003 CAP MPF .015uF 100V 10% C66-68
2 0041903003 CAP MPF .018uF 100V 10% C54-55
2 0027267003 CAP MPF .022uF 100V 10% C34-35
7 0027272003 CAP MPF .047uF 63V 10% C97 C99-100 C102-105
1 0027277003
**CAP MPF .082uF 100V 10%
C110
1 0053860000
**CAP MPF .1uF 250VAC 20%
C106
2 0027278003 CAP MPF .1uF 63V 10% C24-25
2 0027281003 CAP MPF .22uF 63V 10% C92-93
6 0027286003 CAP MPF .47uF 63V 10% C78-79 C91 C94-95 C101
1 0037666002 CAP PFF .001uF 400V 10% C17
1 0024823000 CAP MPF RDL .01uF 400V 10% C20
1 0024845000 CAP MPF RDL .047uF 400V 10% C13
4 0024854000 CAP MPF RDL .1uF 400V 10% C11-12 C16 C23
2 0024862000 CAP MPF RDL .22uF 400V 10% C3-4
1 0064707000 CONTROL SNAPIN 10k B DUAL w/DET
R79 VARI-Q
TM
LEVEL
1 0053929000 CONTROL SNAPIN 10kB250kB DUAL
R26 O.D. BLEND (MIX)
1 0056557000 CONTROL SNAPIN 25k 30A TAPER
R20 MID
3 0027942000 CONTROL SNAPIN 50k 2B DETENT R115 R125 R155
FX TRIM, ROOM BAL, X-OVER BAL
3 0027941000 CONTROL SNAPIN 50k B TAPER R46 R129 R176
O.D. VOL, MASTER VOL, L.O. LEVEL
1 0027945000 CONTROL SNAPIN 100k B TAPER
R37 O.D. GAIN
1 0031089000 CONTROL SNAPIN 100k 10C DUAL
R74 VARI-Q
TM
FREQUENCY
1 0064846000 CONTROL 100k 10C TRIPLE
R143 X-OVER FREQUENCY
2 0064708000 CONTROL 250k 30A w/DPDT
R19 R21 BASS
(pull DEEP),
TREBLE
(pull BRIGHT)
1 0039053000 CONTROL SNAPIN 1MEG 30A TAPER
R22 NORMAL VOLUME
To Next Page
