TBP-1
®
™
(This is the model name for warranty claims)
* Non-serviceable part. Replace complete parent assembly. See PCB EXCHANGE POLICY above.
Unique Fender® part. Order directly from the FMIC Customer Service Department.
** Safety Requirement part. Replacement must match Safety Agency…–Value, if specified –Type, if specified –Approval Mark(s) if on part.
** Both a unique Fender® part and a Safety Requirement part as defined above.
8
PARTS LIST:
MAIN – PCB ASSEMBLY
QTY. PART # DESCRIPTION REFERENCE DESIGNATION
4 0064089001 DIODE 1N4003 D58-61
2 0057351001 DIODE 1400V 1.3A #BYD33V/EBT/R D56-57
45 0006260001 DIODE 1N4448 SIGNAL D1-29 D31-32 D39-41 D43 D45-46 D49
+ D52-53 D55 D62-65
3 0031017001 DIODE ZEN 1N5223B 2.7V 5% LL D47 D51 D54
2 0031729001 DIODE ZEN 1N5231B 5.1V 5% LL D30 D44
8 0031635001 DIODE ZEN 1N5240B 10V 5% LL D33-38 D67-68
7 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-2 P6-10
6 0051094003
**FUSE CLIP PCB 5mm (EXPT)
@ F1-3
2 0013111000
**FUSE TD 20mmx5mm 250v 500mAT
F2-3
2 0027419000 HDR .1 CTR 10 CKT SQ PIN P3-4
1 0027413000 HDR .1 CTR 6 CKT SQ PIN P5
8 0031611000 IC OP-AMP DUAL PC4560 U1 U8 U10 U13 U15-18
11 0016795000 IC OP-AMP DUAL TL072 U2-7 U9 U11-12 U14 U19
2 0041261000 IC VOLT REF LM4040DIZ-10.0 U20-21
1 0013562000 IC REGULATOR +15V MC7815CT U22
1 0013564000 IC REGULATOR -15V MC7915CT U23
2 0050849000 HEATSINK PCB LEVEL 576012U @ U22-23
2 0039420000 SCRW M 4-40X3/8 PHP SS SEMS @ U22-23
2 0097360000 NUT HEX 4-40 EX LOCk @ U22-23
9 0059889000 JACK STEREO R/A w/METAL BUSH J1-8 J10
1 0030755000 LED GREEN T-1 3mm DIFFUSED D66
3 0049948000 LED RED LONG LEAD LUMEX D42 D48 D50
4 0036178000 SPACER LED .5x.1 BRN A6192-1 @ D42 D48 D50 D66
1 0036613000 RELAY DPDT DIP 24VOLT 8.3mA K1
3 0024942001 RES CF 1/4W 22ohm 5% R178-180
2 0024947001 RES CF 1/4W 47ohm 5% R57 R93
4 0024961001 RES CF 1/4W 470ohm 5% R78 R210 R238-239
10 0024965001 RES CF 1/4W 1k 5% R13-14 R99-100 R137-138 R160-163
8 0024969001 RES CF 1/4W 1.5k 5% R3 R23 R39 R42 R67 R184-185 R237
2 0024971001 RES CF 1/4W 2.2k 5% R64-65
1 0029455001 RES CF 1/4W 2.4k 5% R80
1 0024972001 RES CF 1/4W 2.7k 5% R220
2 0026504001 RES CF 1/4W 3.6k 5% R75-76
2 0024975001 RES CF 1/4W 3.9k 5% R97-98
1 0029472001 RES CF 1/4W 4.3k 5% R81
2 0024977001 RES CF 1/4W 4.7k 5% R77 R164
4 0024978001 RES CF 1/4W 5.6k 5% R66 R144-146
2 0024979001 RES CF 1/4W 6.8k 5% R206-207
59 0024981001 RES CF 1/4W 10k 5% R2 R5 R28-29 R31-35 R38 R47 R52-56
+ R58-59 R68-73 R84-92 R103-104
+ R117-119 R121-122 R132-135
+ R147-154 R169-172 R202-203 R216
1 0024983001 RES CF 1/4W 12k 5% R165
2 0029539001 RES CF 1/4W 13k 5% R107-108
3 0024985001 RES CF 1/4W 15k 5% R128 R204-205
4 0029006001 RES CF 1/4W 20k 5% R139-142
