ULTIMATE CHORUS DSP
SPECIFICATIONS
Product Release No.: PR 436 (This is not a model number)
Part Number: 120V Version : 22-6701-020
240V Aus : 22-6731-020
230V UK : 22-6741-020
230V Eur : 22-6761-020
100V : 22-6771-020
Power Requirements: 360W
Power Amp Section
Power output: 65W per channel, (130W total) @ 5% THD
Rated load impedance: 8Ω per chanel
Sensitivity: 1.4V RMS
Preamp Section
Input Impedance: Input 1: >1MΩ, Input 2: >130kΩ
Nominal level: Input 1: 100mV Input 2: 200mV
Mono effects loop: Nominal level: -10dBV
Send output impedance: 1kΩ (balanced)
Return input impedance: 18kΩ (balanced)
Stereo effects loop: Nominal level: -10dBV
Send output impedance: 1kΩ
Return input impedance: 100kΩ
Channels: Left on tip, Right on ring
Speaker Complement: Two 8 Ω Fender Special Design 12" Speakers (P/N 0025923000)
Dimensions: Height:18 1/2" (47 cm)
Width: 26 1/8" (66 cm)
Depth: 10 1/4" (26 cm)
Weight: 47 lbs. (21.3 kg)
Product specifications are subject to change without notice
