ULTIMATE CHORUS DSP
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0040987000 CABLE RIBBON 10 CKT 3.75" PW2
1 0048845000 CABLE RIBBON 12 CKT 3.75" PW14
1 0048914000 CABLE RIBBON 8 CKT 7" PW3
1 0051445003 CAP CD 22pF 500V 5% C27
4 0051457003 CAP CD 100pF 500V 5% C37-38 C60-61
15 0051406003 CAP CD 220pF 500V 10% C31-32 C53-54 C64-68 C72-73 C82-85
7 0051458003 CAP CD 470pF 500V 10% C5 C13 C23 C33-34 C69 C93
1 0051459003 CAP CD 560pF 500V 10% C17
33 0034788003 CAP CR .1uF 50V 20% .2" LS
C46-52 C80-81 C88-89 C98-107 C114-117 C121-128
2 0027255003 CAP MPF .001uF 100V 10% C4 C20
3 0027256003 CAP MPF .0015uF 100V 10% C40-41 C43
3 0027257003 CAP MPF .0022uF 100V 10% C15 C18-19
1 0027259003 CAP MPF .0033uF 100V 10% C16
4 0027261003 CAP MPF .0047uF 100V 10% C1-2 C56-57
2 0027264003 CAP MPF .01uF 100V 10% C8 C55
2 0027265003 CAP MPF .015uF 100V 10% C21-22
2 0027270003 CAP MPF .033uF 100V 10% C9 C11
1 0027272003 CAP MPF .047uF 63V 10% C95
1 0027277003 CAP MPF .082uF 100V 10% C10
4 0027278003 CAP MPF .1uF 63V 10% C26 C86-87 C94
2 0052003003 CAP MPF .1uF 250V 10% C110-111
1 0053860000 CAP MPF .1uF 250VAC 20% C131
5 0027281003 CAP MPF .22uF 63V 10% C7 C25 C70-71 C96
4 0027286003 CAP MPF .47uF 63V 10% C6 C24 C92 C97
2 0033477003 CAP MPF .68uF 63V 10% C42 C44
2 0033606003 CAP AE RDL .47uF 50V 20% C12 C14
8 0028459003 CAP AE RDL 2.2uF 50V 20% C58-59 C74-77 C90 C109
3 0028460003 CAP AE RDL 4.7uF 50V 20% C78-79 C108
11 0028467003 CAP AE RDL 22uF 50V 20% C3 C28-30 C35-36 C39 C62-63 C129-130
3 0028474003 CAP AE RDL 100uF 25V 20% C91 C119-120
1 0028485003 CAP AE RDL 470uF 16V 20% C45
1 0028490003 CAP AE RDL 1000uF 6.3V 20% C118
2 0031756000 CAP AE RDL 4700uF 50V +100%-20% C112-113
2 0027937000 CONTROL SNAPIN 2k 15A TAPER R17 R48
normal mid drive mid
3 0054390000 CONTROL SNAPIN 5k 15A TAPER R68 R71 R75
normal RVB?DLY level drive RVB/DLY level
CHR/MOD level
4 0027940000 CONTROL SNAPIN 50k 15A TAPER R15-16 R46-47
normal treble normal bass drive treble
drive bass
2 0027941000 CONTROL SNAPIN 50k B TAPER R9 R40
normal volume drive volume
1 0027942000 CONTROL SNAPIN 50k 2B DETENT R37
presence
1 0027947000 CONTROL SNAPIN 100k 30C TAPER R27
gain
48 0006260001 DIODE 1N4448 SIGNAL LL
D1-8 D10-35 D45 D47-48 D50-54 D59 D61-63 D65-66
5 0064089001 DIODE 1N4003 LL D40-43 D64
4 0025821001 DIODE HV FDH400 SWITCHING LL D36-39
4 0029045000 DIODE 6A 400V 6A4 LEAD FORMED D67-70
2 0031017001 DIODE ZEN 1N5223B 2.7V 5% LL D56 D58
