ULTIMATE CHORUS DSP
PRINTED CIRCUIT BOARD ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0031635001 DIODE ZEN 1N5240B 10V 5% LL D44 D46 D49 D60
3 0028119060 DIODE ZEN 1N5353B 16V 5W 5% D71-73
1 0041074000 ENCODER 16-POS 4-BIT BINARY S5
13 0025802000 FSTN TAB MALE .250x.032 PCB MT P1-13
2 0051094003 FUSE CLIP PCB 5mm (EXPT) @F1
1 0027421000 HDR .1 CTR 12 CKT SQ PIN P14
7 0031611000 IC OP-AMP DUAL PC4560 U4-10
3 0016795000 IC OP-AMP DUAL TL072 U1-3
1 0041261000 IC VOLT REF LM4040DIZ-10.0 U11
1 0041812000 IC REGULATOR +5V MC7805CT U12
1 0050849000 HEATSINK PCB LEVEL 576012U @U12
1 0039420000 SCRW M 4-40X3/8 PHP SS SEMS @U12
1 0097360000 NUT HEX 4-40 EX LOCK @U12
1 0051658000 JACK MONO R/A J7
6 0053450000 JACK STEREO R/A J1-6
1 0049948003 LED RED LONG LEAD LUMEX D9
1 0030755000 LED GREEN T-1 3mm DIFFUSED D55
1 0049948000 LED RED LONG LEAD LUMEX D57
2 0036178000 SPACER LED .5x.1 BRN A6192-1 @D55 D57
1 0055891000 PCB, MAIN, ULT CHRS DSP
2 0024945001 RES CF ¼W 5% 33ohm LL R138-139
7 0024947001 RES CF ¼W 5% 47ohm LL R83 R114-117 R200-201
2 0028015001 RES CF ¼W 5% 130ohm LL R12 R43
1 0024955001 RES CF ¼W 5% 180ohm LL R81
9 0024961001 RES CF ¼W 5% 470ohm LL R8 R110-113 R132-135
11 0024965001 RES CF ¼W 5% 1k LL R28 R58-61 R102-105 R162-163
5 0028842001 RES CF ¼W 5% 1.1k LL R19 R148-151
1 0028862001 RES CF ¼W 5% 1.3k LL R171
1 0024969001 RES CF ¼W 5% 1.5k LL R177
3 0024973001 RES CF ¼W 5% 3.3k LL R11 R26 R42
5 0024975001 RES CF ¼W 5% 3.9k LL R126-127 R130-131 R165
2 0024977001 RES CF ¼W 5% 4.7k LL R118-119
1 0028034001 RES CF ¼W 5% 5.1k LL R5
2 0024979001 RES CF ¼W 5% 6.8k LL R6 R186
4 0025942001 RES CF ¼W 5% 7.5k LL R23 R38-39 R84
2 0026510001 RES CF ¼W 5% 9.1k LL R72-73
6 0024981001 RES CF ¼W 5% 10k LL R52-55 R189 R191
1 0029002001 RES CF ¼W 5% 11k LL R22
2 0024983001 RES CF ¼W 5% 12k LL R85 R99
5 0024985001 RES CF 1/4W 5% 15k LL R7 R86-87 R172 R187
3 0024986001 RES CF 1/4W 5% 18k LL R69 R76 R166
13 0024987001 RES CF 1/4W 5% 22k LL
R14 R20-21 R32-33 R35 R45 R64-67 R167 R192
2 0028863001 RES CF 1/4W 5% 24k LL R24 R98
6 0024988001 RES CF 1/4W 5% 27k LL R88-89 R122-125
2 0024991001 RES CF 1/4W 5% 39k LL R13 R44
7 0024993001 RES CF 1/4W 5% 47k LL R92-97 R164
4 0028990001 RES CF 1/4W 5% 51k LL R106-109
1 0024994001 RES CF 1/4W 5% 56k LL R10
3 0024995001 RES CF 1/4W 5% 68k LL R1-2 R34
1 0028153001 RES CF 1/4W 5% 75k LL R41
3 0024996001 RES CF 1/4W 5% 82k LL R70 R74 R77
13 0024997001 RES CF 1/4W 5% 100k LL
R49 R56-57 R62-63 R90-91 R100-101 R182 R188 R190 R194
1 0024998001 RES CF 1/4W 5% 120k LL R50
1 0025059001 RES CF 1/4W 5% 220k LL R18
To Next Page
