ULTIMATE CHORUS DSP
CHASSIS ASSEMBLY (cont)
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0031726000 HEATSINK BAR
1 0054642000 CONNECTOR IEC SNAP-IN
1 0039236000 SWITCH ROCKER DPST PSEUDO-IEC
1 0040582000 SWITCH DPST .250 TAB GLOBAL 230V
1 0031668000 XFMR PWR 120v/125w DOMESTIC
1 0039253000 XFMR PWR EXP ULTIMATE CHORUS EXPORT
CABINET ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
REF 037788000 CLOTH GRILLE BLACK/SILVER
4 026566000 CORNER 2 HOLE w/TAB NI
2 026568000 CORNER 3 HOLE NI
4 019276000 GLIDE CAB 1.24x.335 NI
4 019275000 INSERT GLIDE CUSHION 1.27 DIA
1 027846000 HANDLE 9.25" NO LOGO
2 019279000 HANDLE CAP 2 HOLE NI
1 032524000 INSERT HANDLE
4 056482000 MTG PLATE - SWIVEL CASTER
12 021972000 NUT T 10-32x3/4 STR 3 PRNG BLX
4 022244000 SCRW M 10-32x1-1/8 OHP NI
10 026571000 SCRW SMAB 8x5/8 THP NI
4 026625000 SCRW WOOD 8x1 FH
16 027199000 SCRW SMAB 10x3/4 PHP NI
REF 026570000 TOLEX BRAVURA BLACK
REF 029085000 VELCRO STRIP LOOP 1.5"wd BLK
REF 029086000 VELCRO STRIP HOOK 1.5"wd BLK
END ITEM
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0040071000 CAB ASSY ULT CHORUS/STAGE160
1 0055899000 CHS ASSY ULT CHRS DSP 120V
REF 0055900000 CHS ASSY ULT CHRS DSP 230V
REF 0055901000 CHS ASSY ULT CHRS DSP 240V
REF 0055902000 CHS ASSY ULT CHRS DSP 100V
4 0023513000 CASTER SWIVEL
1 0047248000 CORD PWR W/IEC CONN DOM
REF 0047251000 CORD PWR W/IEC CONN 230V
REF 0047249000 CORD PWR W/IEC CONN 230V UK
REF 0047250000 CORD PWR W/IEC CONN 250V
REF 0053997000 CORD PWR W/IEC CONN 100V JPN
