ULTIMATE CHORUS DSP
DSP PCB ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
4 0053544004 XSTR NPN 2N2222 SMT Q1-4
1 0053536004 IC, DSP, 56L811 U1
2 0053537004 SRAM, LOW VOLTAGE 32Kx8, SMT U2-3
1 0055764000 PROGRAMMED EPROM U4
1 0053540004 IC, CODEC, AK4520A U5
1 0053541004 VOLT REGULATOR 3.3V W/R, SMT U6
1 0049948000 LED RED LL LUMEX D6
1 0036178000 SPACER LED .5x.1 BRN A6192-1
2 0041074000 ENCODER S1,S2 BREAK OFF LOCATING TABS-2PLCS
1 0027419000 HDR .1 CTR 10 CKT SQ PIN P2
1 0027416000 HDR .1 CTR 8 CKT SQ PIN P3
2 0053555004 CAP CER 0805 22pF 25V 5% C10-11
1 0053558004 CAP CER 0805 750pF 25V 5% C13
2 0053557004 CAP CER 0805 .001uF 25V 5% C29-30
2 0053559004 CAP CER 0805 .0039uF 25V 5% C33-34
5 0053556004 CAP CER 0805 .01uF 25V 5% C12 C16 C19 C38-39
17 0053554004 CAP CER 0805 .1uF 25V 5% C1-9 C14-15 C18 C22-23 C25 C27 C36
2 0053560004 CAP TAN 3528 4.7uF 15V 20% C31-32
7 0053561004 CAP TAN 3528 10uF 15V 20% C17 C21 C24 C26 C28 C35 C37
2 0055777004 RES MF 0805 1/10W 0 ohm R59 R61
3 0053547004 RES MF 0805 1/10W 10 ohm 5% R15-17
4 0053552004 RES MF 0805 1/10W 150ohm 5% R40-43
2 0053550004 RES MF 0805 1/10W 180 ohm 5% R34-35
8 0053549004 RES MF 0805 1/10W 560 ohm 5% R25 R27-29 R54-R57
1 0053546004 RES MF 0805 1/10W 2k 5% R2
4 0053548004 RES MF 0805 1/10W 3.3k 5% R24 R26 R30-31
32 0053545004 RES MF 0805 1/10W 10k 5% R3-14 R18-23 R36-39 R44-53
2 0053551004 RES MF 0805 1/10W 47k 5% R32-33
1 0053553004 RES MF 0805 1/10W 1M 5% R1
1 0053542004 CRYSTAL, 10 MHz, SMT Y1
1 0053539004 IC SOCKET, 32 PLCC, SMT @ U4
1 0053570000 PCB FAB, DSP SFX SERIES
CHASSIS ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
1 0055898000 CHASSIS ULTIMATE CHORUS DSP
1 0053884000 FUSE QA 20mmX5mm 125V4A ULCSA
1 0020794000 FUSE QA 20mmx5mm 250v 2A 230V/240V
1 0055892000 PCB ASSY ULT CHRS DSP (MEX)
1 0055590008 PCB ASSY DSP PRCN CHR DSP
5 0028500000 SCRW TF 8-32x3/4 HWH SLTD Z1 chassis to heatsink
2 0021709000 BUSHING SR .437x.062x13/32 BLK @speaker wires
4 0051404000 STANDOFF NYLON BLK .375 @PCBs
16 0026402000 KNOB POINTER BLACK
1 0033045000 END BELL XFMR PWRCH @xfmr
4 0028591000 NUT ACORN 8-32 @xfmr
4 0030007000 WSHR LCK INTL 8x.330x.02 ZI @xfmr
1 0038900000 SCRW TF 6-32X1/4 PHP ZI ground
7 0055838000 NUT PLASTIC BLK REAN JACK
1 0055896000 PANEL FRNT ULT CHRS DSP
1 0055897000 PANEL REAR ULT CHRS DSP
