Ferm CDM1112S - Adjusting the gears; Adjusting the torque; Adjusting the direction of rotation; Switching the machine on and off

9
EN
• Checkifthebitiscenteredwellbyshortly
activating the machine´s on/off switch.
Adjusting the gears
Fig. F
Never switch gears when the motor is
running, this will damage your machine.
Never put switch in the middle between
both positions, this will damage your
machine.
The machine has 2 drill speeds, which can be
adjustedbyslidingthegearswitch(8)forwardor
backwards.Thenumberonthegearswitch(8)
shows which position is chosen.
• Position1:Forslowdrilling,largedrilling
diameter or screw driving. The machine has
high power at a low speed.
• Position2:Forfastdrillingorsmalldrilling
diameter
Adjusting the direction of rotation
Fig. G
• Setthedirectionswitch(9)toposition in
order to drive screws or to use it for drilling.
• Setthedirectionswitch(9)toposition in
order to remove screws.
Switching the machine on and off
Fig. G
Theon/offswitch(10)isusedforactivatingthe
machine and adjusting rotation speed.
• Pressingtheon/offswitch(10)willactivate
the machine, the further the switch is being
pushed, the faster the drill will turn.
• Releasingtheon/offswitch(10)willstopthe
machine.
• Movethedirectionreversingswitch(9)tothe
middle position to lock the movement of the
on/off switch. It cannot be activated in this
position.
Only lay down the machine when it has
stopped running completely. Do not
place it on a dusty surface as particles of
dust could get into the mechanism.
Adjusting the torque
Fig. G
The machine has 20 different torque settings
and a special drill mode to set the power being
transmitted to the chuck.
Byrotatingthetorqueadjustmentring(11),
screws can be driven to a predetermined depth,
which is ideal for repetitive work. The higher the
number, the more torque will be transmitted.
• Selectalowsettingforsmallscrewsorsoft
work material.
• Selectahighsettingforlargescrews,hard
work materials and when removing screws.
• Youshouldpreferablychooseasettingas
low as possible when driving screws. Select
a higher setting if the motor slips before the
screw is fully tightened.
• Fordrilling,turnthetorqueadjustmentring(11)
tothesettingfordrilling(
) by fully turning it
counterclockwise.
Ensure that the direction switch (9) is
always set to during drilling.
The machine is equipped with electronic
overload protection function. When the
machine gets overloaded it will shut
down automatically. When this happens,
please wait for a few seconds to let the
overload protection reset itself.
Work light (12)
Fig. A
The machine is equipped with a work light to
illuminate the work location.
• Itautomaticallyswitchesonwhentheon/off
switch is being pressed.
• Itautomaticallyswitchesoffwhentheon/off
switch is released again.
Belt hook (13)
Fig. A
The machine is equipped with a belt hook for
hanging the machine to your belt during use.
Always switch the direction switch (9) to
middle position to avoid accidental
startup of the machine.
