Ferm
MITRE SAW
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europeís leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive Warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the text refer to the diagrams
on pages 2-4.
Read the operating instructions
carefully before using this device.
Familiarize yourself with its functions
and basic operation. Service the device
as per the instructions to ensure that it
always functions properly. The
operating instructions and the
accompanying documentation must be
kept in the vicinity of the device.
Intended use
The electro tool is intended as a stationary
machine for making straight lengthways and
crossways cuts in wood. Horizontal mitre angles
of -45° to +45° as well as vertical bevel angles of
-45° are possible.
Contents
1. Machine information
2. Safety instructions
3. Assembly and accessories
4. Operation
5. Service & maintenance
Check the appliance, any loose parts and
accessories for damage caused during transport.
1. MACHINE INFORMATION
Technical specifications
Voltage 230 V
Capacity 1400 W
Machine class (double insulated) II
Revolutions, not under load 5000/min
Saw blade measurement 210x30x2.8mm
Angle for mitring (left and right) 45º
Angle for bevelling (only left) 45º
Mitre saw max. sawing capacity:
Mitre 0º, Bevel 0º 50x120 mm
Mitre 45º, Bevel 45º 30x80 mm
Mitre 45º, Bevel 0º 50x80 mm
Mitre 0º, Bevel 45º 30x120 mm
Weight 5.62 kg
Lpa (sound pressure) 88.7+3 dB(A)
Lwa (acoustic capacity) 101.7+3 dB(A)
Vibration level 2.694 m/s
2
Features
Figs. A
1. On/off switch
2. Locking lever for saw head
3. Locking knob for saw head
4. Grip
5. Saw blade
6. Guard
7. Spindle lock button
8. Locking knob for mitre angle
9. Scale for mitre angle
10. Locking knob for bevel angle
11. Scale for bevel angle
12. Saw head
13. Saw table
14. Guide fence
15. Dustbag connection
16. Carbon brush holder
17. Transport grip
18. Mounting hole
2. SAFETY INSTRUCTIONS
Explanation of the symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
