Motor
Connect the machine to a 220/230 V socket.•
If the motor does not start, immediately •
release the switch. Take the plug out of the
socket. Check that the saw blade can turn
freely. If so, try starting the machine again.
To prevent damaging the motor must be
regularly freed of chips and dust to
ensure correct cooling.
If the motor suddenly stops while sawing, let •
go of the switch immediately. Loosen the saw
blade from the piece of work, after which
sawing can continue.
Using long cables of too small a diameter can •
result in loss of voltage, which can lead to
problems with the motor.
For a length up to 15 metres a cable must •
be used with a diameter of 1.5 mm
2
.
For a length of between 15 and 40 metres •
a cable must be used with a diameter of
2.5 mm
2
.
3. ASSEMBLY AND
ACCESSORIES
Installation of the machine on a workbench or
on the subframe.
This machine is a stationary machine and for
safety reasons must always be firmly installed
and not used for mobile applications.
You can install the machine in two ways:
a. As a stationary machine on a workbench. In
this case the machine must be secured to the
workbench with 4 bolts.
b. As a stationary machine on the subframe.
In this case the machine must be secured to
the subframe with 4 bolts and the subframe
anchored to the floor or to a floor plate with
dimensions of at least 1 square metre.
Mounting and removing the saw blade
Fig. A+B
Do not use the machine without the
guard.
Mounting
Pull out the locking knob (3) and raise the saw •
head (12).
Loosen the bracket (29) by removing the •
screw (30).
Raise the guard (6).•
Keep the spindle lock button (7) pressed and •
loosen the bolt (19) using the spanner (20).
Remove the flanges (21 & 22).•
If necessary, clean the flanges (21 & 22).•
Mount the flange (22).•
Mount the saw blade (5). Make sure that the •
arrow on the saw blade points in the same
direction as the arrow on the saw head.
Mount the flange (21).•
Keep the spindle lock button (7) pressed and •
tighten the bolt (19) using the spanner (20).
Lower the guard (6).•
Mount the bracket (29) by tightening the •
screw (30).
Removing
Pull out the locking knob (3) and raise the saw •
head (12).
Loosen the bracket (29) by removing the •
screw (30).
Raise the guard (6).•
Keep the spindle lock button (7) pressed and •
loosen the bolt (19) using the spanner (20).
Remove the flange (21).•
Remove the saw blade (5).•
Mount the flange (21).•
Keep the spindle lock button (7) pressed and •
tighten the bolt (19) using the spanner (20).
Lower the guard (6).•
Mount the bracket (29) by tightening the •
screw (30).
Setting the mitre angle
Fig. C
The mitre angle is left/right variable between •
0° and 45°. The mitre angle can be read from
the scale (9).
Do not set the mitre angle during use.
Slacken the locking knob (8).•
Turn the saw table (13) to the required •
position.
Tighten the locking knob (8).•
Setting up the double sawing angle / mitring
Fig. D
Adjust the first angle as described for •
adjusting the saw angle (above).
