Copy (COP)
This operation aims to copy all the data from one reader to another. The following data is
copied:
- List of User Fingerprints (L.NN)
- Configuration (C.NN)
Enter the destination reader number where all the data from the current reader will be
copied. The reader number to be copied or the destination reader explained in the option:
“Network Identifier (nEt)”.
The readers have to be connected using terminals A and B. See diagram.
Standby Mode
2. Search using the menu’s scroll keys:
COP
1. Enter the master fingerprint.
Enter Programming Mode
default
value: 0
3. COP is shown. Confirm with the OK key.
1 beep
1 beep
For example: Destination reader 3 (the green LED of the destination reader will flash whilst it is receiving the
information).
4. Enter a destination reader number of between 1 and 127, on which the system data will be stored.
NOTE: the copying time is proportional to the number of fingerprints stored. Do not disconnect
until the process is finished.
1 beep
Clone diagram
