Fermax VIDEO DIGITAL COLOR KIT - Accessories

Pag 40
Vac
INT.
EXT.
INT.
EXT.
ALIMENTACION
FUENTE DE
REF.6062
Vac
-+-+
TELECAMARA
+
-
AMPLIFICADOR ADS AMPLIFICADOR ADS
1
1
-+
CT VM
L
+
-
BXCt SL AbBAb
+
X
-
BXCt SL AbBAb
+
X
-
Wiring for ADDITIONAL AUDIO PANEL KITS
TO THE MONITORS
MAIN PANEL
ADDITIONAL PANEL
1
2
HIGH RESOLUTION
FLAT MONITOR
HIGH RESOLUTION
CCD CAMERA
PAN &TILT
NOTE:
Terminals can only be programmed from the main panel (JP1 connected).
* SURFACE BOX (REF.8951, 8954 y 8955): To install the Outdoor Panel
in places where there is no possibility of flushing in the wall (marble, thin
walls, etc.)
* CONVERSION FRAMES (REF.8991, 8994 y 8995) Used for covering the
gap in the wall from previous installations.
* ELECTRONIC EXTENSION CALL (REF.2040) See next page.
* STAIRS LIGHT RELAY (REF.2013) See pages 41 and 42.
* LIGHT COMMANDER (REF.8053) Allows to activate buzzers and devices
supplied with 220 Vac.
* CORNER BOX (REF.8378, 8381 y 8382) To improve the orientation of
the Outdoor Panel when it is installed in places with difficult access.
ACCESORIES
The following are some examples of FERMAX accesories that can be used
with the KIT, and some examples of typical installations with these devices.
Connect
JP1
Do not
connect JP1
