Features
4.2 Lift-First Control Handles
A “Lift-First” style control handle requires the operators to lift the
weight of the cot, patient and accessories o the locking mechanism
before pulling the control handle. When operated, the control handles
disengage the locking mechanism and allow the cot to be raised or
lowered.
Lift-First control handles are located on the patient-right side, at the
control end and center of the cot (Figure 2).
Only trained operators use the control handles.
To adjust the cot height, the trained operators stand on opposite sides
or ends of the cot. Communicate and lift the weight before operating a
control handle.
Refer to “Changing Positions” on page 14 for complete instructions.
Control Handles
2
4.3 Swing-Down Sidearms
Sidearms help provide patient security and comfort. Keep sidearms
raised except when transferring a patient onto or o from the cot.
To lower, pull the lock pin with one hand and lower the sidearm with
your other hand (Figure 3).
To raise, swing the sidearm up until it locks.
NOTICE
Do not use the sidearms to lift the cot. Sidearms are not
designed for lifting. Lift the cot only by grasping the main
frame.
3
4.4 Telescoping Frame
The cot loading-end frame telescopes inward to shorten the overall
length of the cot. This allows operators to maneuver the cot more easily
in conned spaces such as a narrow hallway or elevator.
To shorten the cot, raise the backrest and push the frame toward the
operator end. To extend, pull the frame away from the operator end
(Figure 4).
Fully extend the frame before lowering the backrest.
4
