Ferroli SUN Series User Manual

S.p.A.
14
SUN
1 3340089/0 Elbow, 1/8 M, 4 diam. coupling
2 3370093/0 Washer, int. diam. 13.5, ext. diam. 18 x 2
3
4
5 3560092/0 Pump, model AS47A 1564 IP 0500
6 3560100/0 Nut, M8
7 3560217/0 Deflector, art. 94040 Meku
8 3560156/0 Nipple, 3/8” - 1/4”
9a 3560086/0 Preheater (for G6R only)
9b 3560207/0 Nozzle holder (for G6 version)
10 3560162/1 Cable, length 330 with resistance
11 3560167/0 Burner shield
12 3560168/0 Burner screw stoker
13 3560169/0 Motor, clockwise rotation, 70W
14 3560170/0 Burner fan, 146 x 49 F. 12.7 LHR
15 3560171/0 Transformer, Brahma art. TP2STPAF 55 VA
16 3560172/0 Oil feed pipe
17 3890000/0 Air regulation shaft
18
19 3560176/0 Air deflector
20 3560177/0 Air regulation
21 3560178/0 Air damper pin
22 3560179/0 Draught tube art. 98008 Meku
23 3560180/0 Stoker screw cover
24 3560181/0 Spray nozzle shaft
25 3560182/0 Grommet for electrodes
26 3560183/0 Burner casing
27 3560184/0 Reset button
28 3560185/0 Flange
29 3560186/0 Flange gasket
30 3560204/0 Flexible hose ST6 1/4” FC - 1/4” MG, length 900
31 3650360/0 Connector M. 7P art. S7P - M - STD - T14
32 3890112/0 Control unit assembly
33
34 3560173/0 Photoelectric cell
35 3560208/0 Preheater bridge burner Sun G6
Pos. Code Description
LIST COMPONENTS

Ferroli SUN Series Specifications

General

Model	SUN Series
Category	Burner
Control	Electronic
Dimensions	Varies by model
Efficiency	Up to 93%
NOx Emissions	< 70 mg/kWh (Class 5)
