AUDIO IN
USB MIDI
After the board
The bottom of the
left side of the host
Port 1
Headphone Output
1. This product has two headphone output jacks, before connecting the
headphones, please be sure to first turn down the volume of the digital piano.
After connecting the headphones, please turn down the volume of the digital
piano first, and then adjust the volume back to your satisfaction.
2. Connecting headphones will automatically cut off the output of the digital
piano's built-in speakers, so you can play late at night without disturbing
others.
Port 2
AUDIO OUT
DC 15V
Dual Headphones Jacks
Volume Knob
Power Switch
Control Panel
FUNCTIONAL INDICATOR
JACK SOCKET
HEADPHONE PORT
3 4
